0015D010BH4HC HYDAC High Pressure Filter Element

Product Overview

The 0015D010BH4HC High Pressure Hydraulic Oil Filter Element is an engineering-grade, heavy-duty filtration element strictly manufactured to DIN 24550 specifications. Designed as a direct 100% interchangeable replacement for HYDAC 0015 D series high-pressure elements (including 0030D, 0055D, 0060D, 0075D, 0095D, and 8.900D variants), this filter utilizes premium multi-layer inorganic glass fiber media (Betamicron® BH4HC high-collapse media) supported by reinforced heavy-duty inner and outer steel cores. Rated for a collapse pressure of up to 210 bar, every unit undergoes 100% simulated high-pressure testing to maintain absolute fluid cleanliness (ISO 4406 standard) and prevent element fatigue or collapse in non-bypass high-pressure lines, reliably protecting axial piston pumps, hydraulic motors, and sensitive servo/proportional valves.

Technical Specifications

• Model Code: 0015D010BH4HC (Cross-compatible series: 0015D005BH4HC, 0030D, 0055D, 0060D, 0075D, 0095D, 8.900D010BH)

• Filtration Rating: 10 µm absolute ($\beta_x(c) \ge 1000$)

• Filter Material: BH4HC (High-collapse multi-layer inorganic glass fiber, Betamicron® technology)

• Collapse Pressure Rating: 210 bar (21.0 MPa / 3045 psi) high-collapse version

• Operating Temperature Range: -30°C to +100°C (-22°F to +212°F)

• Sealing Material: NBR (Nitrile Rubber standard, FKM/Viton optional)

• Flow Direction: Out-to-In

• Standard Specification: DIN 24550 compliant (D series high-pressure filter element without bypass valve)

• Net Weight: Approx. 0.18 kg

Key Technical Advantages

• 210 Bar High-Collapse Structural Integrity: Engineered with heavy-duty galvanized inner cores and outer support mesh specifically for non-bypass high-pressure line applications, preventing media collapse during extreme pressure spikes or cold startup conditions.

• Betamicron® Optimized Pleat Geometry: Multi-layered inorganic glass fiber media provides exceptional porosity and high surface area, yielding over 30% greater dirt-holding capacity and significantly extending service life.

• Minimal Initial Delta-P ($\Delta p$): Precision-spaced pleating minimizes internal restriction, reducing energy consumption and protecting upstream high-pressure pumps against cavitation.

• 100% Drop-In DIN 24550 Interchangeability: Manufactured strictly to OEM envelope dimensions and machining tolerances, allowing seamless direct replacement in original filter housings without modifications.

Application Areas

• Metallurgy & Steel Mills: Continuous casting machines, AGC roll positioning hydraulic systems, and servo valve protection.

• Plastics & Injection Molding: High-tonnage injection molding machinery and servo-hydraulic power packs.

• Heavy Mining & Construction Equipment: Excavator high-pressure pump outlets, rotary drilling rigs, and hydraulic crushers.

• Industrial Machine Tools & Power Units: CNC hydraulic systems and heavy forging press hydraulic power units (HPU).

Expert Maintenance Tips

• Differential Pressure Indicator Setup: Because high-collapse elements (BH series) are routinely used in non-bypass inline safety applications, ensure a differential transmitter is active. Replace the 0015D010BH4HC element when differential pressure reaches 5.0 bar, and do not exceed 8.0 bar.

• O-Ring Lubrication Protocol: Thoroughly clean the interior housing cavity prior to inserting the new element. Pre-lubricate the target O-ring and back-up ring with clean system hydraulic fluid to prevent seal twisting or tearing during high-pressure seating.

• Fluid Contamination Sampling: Perform fluid particle counts (ISO 4406) during filter element servicing to proactively detect internal component wear on upstream pumps and motors.
