26007-LZK Eaton Series 26 High Pressure Low Noise Gear Pump 210bar

Product Overview

The 26007-LZK, 26008-LZA, 26008-RZD, 26009-RZH, 26010-RZB and 26011-RZC models are high-pressure low-noise external gear pumps fully interchangeable with the genuine Eaton/Danfoss (formerly Vickers) Series 26 (26000 Series). Featuring 13-tooth precision gears and optimized trap reliefs, these pumps deliver reduced flow ripple and quiet operation. The die-cast aluminum housing with fixed bushings provides high rigidity and long service life. Every unit undergoes 100% simulated duty-cycle testing to guarantee exact matching of SAE-A flange, shaft ends, ports and performance curves with original Series 26 pumps. Ideal for agricultural, construction and industrial hydraulic systems, they offer a reliable drop-in replacement that reduces spare-part costs and downtime.

Technical Specifications

• Models: 26007-LZK / 26008-LZA / 26008-RZD / 26009-RZH / 26010-RZB / 26011-RZC (Eaton/Danfoss Series 26)
• Displacement (26007): 19.7 cm³/rev (1.20 in³/rev)
• Displacement (26008): 22.5 cm³/rev (1.37 in³/rev)
• Displacement (26009): 24.3 cm³/rev (1.48 in³/rev)
• Displacement (26010): 25.2 cm³/rev (1.54 in³/rev)
• Displacement (26011): 27.7 cm³/rev (1.69 in³/rev)
• Continuous pressure: 210 bar (3000 psi)
• Intermittent pressure: 240 bar (3500 psi)
• Max speed: 3000–3600 rpm (size dependent; ≈3200 rpm for 26007, ≈3000 rpm for larger sizes)
• Min speed at continuous pressure: 750 rpm
• Control type: Fixed displacement external gear pump (field reversible)
• Mounting flange: SAE A 2-bolt
• Shaft options: 3/4″ 11T spline, 3/4″ keyed, 5/8″ 9T spline, 5/8″ keyed, etc.
• Ports: Side or rear SAE O-ring (pressure 7/8-14 UNF, suction 1-5/16-12 or 1-1/16-12 UN)
• Housing material: Die-cast aluminum
• Max continuous operating temperature: 105°C

Key Technical Advantages

1. 13-tooth gear design significantly reduces flow ripple and operating noise compared with traditional 10-tooth gears, ideal for noise-sensitive applications.
2. Optimized trap reliefs and inlet-oil bearing lubrication improve volumetric and mechanical efficiency, lowering input power requirements and extending service life.
3. Die-cast aluminum housing with fixed bushings provides high structural rigidity capable of withstanding high pressure and supporting multi-function configurations.
4. Full dimensional interchangeability with genuine Eaton/Danfoss Series 26 (SAE-A flange, shafts and ports) verified by rigorous testing, enabling true drop-in replacement.
5. 100% simulated duty-cycle testing covering pressure, speed and flow curves guarantees factory performance matching original units; field-reversible design requires no extra parts.

Application Areas

Agricultural tractors and harvesters, construction machinery auxiliary circuits, forklifts, skid-steer loaders, fan drive systems, steering circuits, charge pumps, industrial equipment and other mobile or stationary hydraulic systems requiring high-pressure low-noise gear pumps.

Expert Maintenance Tips

• Ensure precise shaft alignment with a flexible coupling; avoid applying radial or axial loads directly to the shaft end.
• Keep suction line diameter at least equal to the pump inlet, minimize length and fittings, and maintain inlet vacuum no higher than 0.8 bar abs to prevent cavitation.
• On first start-up, set the system relief valve to the lowest setting, run at low speed under no load for several minutes to purge air, then gradually raise pressure.
• Use anti-wear hydraulic oil with minimum continuous viscosity of 5.7 cSt and maintain high fluid cleanliness; replace filters regularly.
• For field reversal, follow the procedure to swap drive and idler gears and reposition the plug; periodically inspect shaft seals and mounting bolts.
