112-1058-006 Char-Lynn Eaton 6000 Series Orbital Motor

Product Overview

The 2K / 4K / 6K (2000 / 4000 / 6000 Series), 101 / 112 / 159 / 103 series and specific models 112-1058-006, 159-0051-005, 103-1606-012, 101-1073-009 are Char-Lynn / Eaton (Danfoss) low-speed high-torque orbital hydraulic motors (Geroler disc-valve and Gerotor spool-valve series). Featuring precision rotor set designs, they deliver high starting torque, high volumetric efficiency, and excellent side-load capacity. Fully interchangeable with genuine Char-Lynn / Eaton units and subjected to 100% simulated operating condition testing, these motors provide reliable performance for medium- to heavy-duty mobile and industrial applications.

Technical Specifications

• Model: 112-1058-006 (Char-Lynn 6000 Series)
  • Displacement: 195.8 cm³/rev (11.95 in³/rev)
  • Continuous differential pressure: approx. 205 bar (3000 psi)
  • Intermittent/peak differential pressure: approx. 310 bar
  • Maximum continuous speed: approx. 485–775 rpm
  • Maximum continuous torque: approx. 575 Nm
  • Maximum continuous flow: approx. 150 L/min
  • Control type: Fixed-displacement Geroler disc valve, bidirectional
  • Approximate weight: 15–18 kg
• Model: 101-1073-009 (Char-Lynn H Series typical)
  • Displacement: small-to-medium range (approx. 50–150 cm³/rev)
  • Continuous pressure drop: approx. 124 bar
  • Control type: Fixed-displacement Gerotor spool valve
  • Approximate weight: 8–12 kg
• Model: 103-1606-012 (Char-Lynn S Series typical)
  • Displacement: medium range
  • Continuous pressure drop: approx. 135–140 bar
  • Control type: Fixed-displacement Geroler
  • Approximate weight: 10–14 kg
• Model: 159-0051-005 (Char-Lynn T Series typical)
  • Displacement: medium range
  • Continuous pressure drop: approx. 155 bar
  • Control type: Fixed-displacement orbital
  • Approximate weight: 10–15 kg

(Note: Data based on typical values from Char-Lynn / Eaton official technical literature. Exact shaft, flange, and port configurations depend on the full model code.)

Key Technical Advantages

• Precision Geroler / Gerotor rotor set delivers high volumetric efficiency and smooth low-speed operation.
• High starting torque and excellent side-load capacity ideal for heavy-load starting and high side-load applications.
• Robust bearings and high-pressure shaft seal design support elevated return pressure for extended service life.
• Full drop-in interchangeability with genuine Char-Lynn / Eaton units plus 100% simulated duty-cycle testing ensure reliable performance while reducing maintenance costs.

Application Areas

Agricultural machinery, construction equipment, snow removal and sweeping equipment, forestry machinery, conveyor systems, material handling equipment, industrial drives.

Expert Maintenance Tips

Verify system cleanliness and oil viscosity before installation. Ramp pressure gradually on start-up to avoid dry running. Periodically inspect shaft seals and bearings. Prefer verified interchangeable units for replacement to ensure exact port and flange match. Observe intermittent duty time limits and maintain proper oil cleanliness to maximize service life.
