6SD50N60T-L Taiyo 160S Compact Hydraulic Cylinder

Product Overview

The 6S, 35S, 160S, 210S, 35Z and 10A series (specific model 6SD50N60T-L) are Taiyo compact high-pressure hydraulic oil cylinders featuring steel body construction and precision manufacturing for space-constrained high-pressure applications. Fully interchangeable with Taiyo 160S-1 series dimensions and interfaces, they install directly as drop-in replacements without modifying mounts or plumbing. Every unit undergoes 100% simulated operating condition testing to ensure reliable performance under high pressure, vibration and continuous loading, making them ideal for systems requiring high push/pull force and precise control.

Technical Specifications

• Model: 6SD50N60T-L (6S / 35S / 160S / 210S / 35Z / 10A series)
• Bore diameter: 50 mm (series covers φ20–φ125 mm)
• Stroke: 60 mm (customizable)
• Acting type: Double-acting single rod
• Construction: Compact design
• Nominal pressure: 16 MPa (160 bar for 160S series); higher pressure options available (210S etc.)
• Piston rod thread: T (male thread)
• Seal system: Hydrogenated nitrile rubber or high-performance seals
• Operating temperature range: Up to 120 °C (depending on seals)
• Test standards: Compliant with Taiyo original specifications and related ISO standards

Key Technical Advantages

• Compact high-strength construction: Steel cylinder body and special copper alloy bearing design deliver high output force and long service life within limited space.
• Full interchangeability: Manufactured to exact Taiyo 160S-1 series dimensions and mounting interfaces for true drop-in replacement, minimizing downtime.
• Precision machining and sealing system: Precision-machined tube and hard-chrome plated piston rod combined with wear-resistant seals reduce internal leakage, improve volumetric efficiency and extend service life (up to 10 million cycles).
• Rigorous quality control: Every cylinder undergoes 100% simulated duty-cycle testing to verify pressure integrity, leakage and fatigue performance for long-term industrial reliability.

Application Areas

Injection molding machines, die-casting machines, machine tools, automation equipment, test stands, material handling equipment, and industrial hydraulic systems requiring compact high-pressure double-acting push/pull control. Especially suitable for OEM equipment and retrofit projects.

Expert Maintenance Tips
