A4VSO250DR Rexroth Axial Piston Pump 250cc 350 bar DR

Model Number	A A4VSO 250 DR /30R-FPB13N00

Product Description

Product Overview

The A4VSO250DR/30R-FPB13N00 is the 250 cc-class core model within the Bosch Rexroth A4VSO series of open-circuit axial piston variable displacement pumps. The A4VSO series features a swashplate design where pump flow is proportional to input drive speed and displacement, with displacement steplessly adjustable from zero to maximum. Designed for open-circuit hydrostatic drives, the series operates at a nominal pressure of 350 bar with peak pressure of 400 bar.

Model Code Breakdown (for procurement and engineering reference):

A4VSO: Rexroth open-circuit swashplate axial piston variable pump
250: Nominal size (NG), geometric displacement 250 cm³/rev
DR: Pressure Control — automatically reduces displacement when system pressure reaches the setpoint to maintain constant pressure, suitable for open-circuit systems requiring constant pressure output
/30R: Series 30, clockwise rotation (viewed from shaft end)
FPB13N00: F = F-type seal and fluid compatibility configuration; PB = mounting flange and port code; 13 = port configuration code; N00 = additional configuration code

A4VSO250 Series General Specifications:

Nominal Pressure: 350 bar (continuous)
Peak Pressure: 400 bar (intermittent)
Geometric Displacement: 250 cm³/rev
Maximum Speed: 1800 rpm
Weight (A4VSO…DR control configuration): Approx. 186 kg

Drop-in Replacement Advantage: Manufactured to exact Rexroth OEM specifications, this pump achieves complete drop-in interchangeability with the original A4VSO series for mounting flange, shaft dimensions, port layout, and control module interface. The A4VSO series delivers excellent suction characteristics, short control response times, and low operating noise. Every pump undergoes 100% simulated load testing prior to shipment, validating DR pressure control response, volumetric efficiency, and thermal stability under conditions replicating real-world duty cycles.

Technical Specifications

Model A4VSO250DR/30R-FPB13N00:

Model Code: A4VSO250DR/30R-FPB13N00
Series: Rexroth A4VSO Series 30 (Open Circuit, Swashplate Design)
Nominal Size: NG 250
Geometric Displacement: 250 cm³/rev
Nominal Pressure: 350 bar (continuous)
Peak Pressure: 400 bar (intermittent)
Maximum Speed: 1800 rpm
Theoretical Flow at 1500 rpm: 375 L/min
Maximum Theoretical Torque (Δp = 350 bar): Approx. 1393 N·m
Maximum Power (Δp = 350 bar, n nom): Approx. 219 kW
Control Type: DR — Pressure Control
Pressure Setting Range: 20–350 bar
Rotation: Clockwise (viewed from shaft end, /30R code)
Mounting Flange: ISO 3019-2 4-bolt flange (PB code specification)
Shaft: Splined shaft (ANSI B92.1)
Main Ports: SAE flange with metric bolts
Housing Material: High-strength cast iron
Seal Material: NBR, suitable for mineral oil-based hydraulic fluid
Fluid Cleanliness: ISO 4406 18/15/12 or better
Weight (A4VSO…DR control configuration): Approx. 186 kg
Through Drive Capability: Supports mounting of subsequent pumps of same or smaller size

A4VSO Series Displacement Size Reference:

A4VSO40: 40 cm³/rev, DR control weight approx. 54 kg
A4VSO71: 71 cm³/rev, DR control weight approx. 87 kg
A4VSO125: 125 cm³/rev, DR control weight approx. 103 kg
A4VSO180: 180 cm³/rev, DR control weight approx. 103 kg
A4VSO250: 250 cm³/rev, DR control weight approx. 186 kg
A4VSO355: 355 cm³/rev, DR control weight approx. 206 kg

Key Technical Advantages

1. DR Pressure Control with Constant Pressure Output
The A4VSO250DR/30R-FPB13N00 is equipped with a DR pressure controller. When system pressure reaches the setpoint, the pressure controller automatically reduces pump displacement, maintaining only leakage compensation flow to keep system pressure constant. The pressure setting range is 20–350 bar, precisely settable via the adjustment screw. The DR control offers short response times, rapidly stabilizing system pressure under load transients — ideal for hydraulic presses, test benches, and other industrial hydraulic systems requiring constant pressure output. The pressure controller is not a safeguard against pressure overload; a pressure relief valve must be installed in the hydraulic system.

2. Swashplate Design with High Volumetric Efficiency
The A4VSO series employs a swashplate axial piston rotary group design where swashplate inclination angle determines piston stroke and displacement. Pistons and cylinder bores are precision match-ground to micron-level clearances. Valve plate pre-compression and pre-decompression angles are CFD-optimized to minimize pressure spikes and flow pulsation. Volumetric efficiency remains above 95% at 350 bar continuous pressure. The swashplate configuration offers compact axial dimensions suitable for space-constrained industrial installations.

3. High-Strength Cast-Iron Housing with Long Service Life
The housing is precision-cast from high-strength cast iron, with the material’s damping characteristics effectively suppressing structural vibration and fluid-borne noise. The A4VSO series is renowned for exceptionally long service life, with bearings selected through system-level load analysis for long-term operation at 350 bar continuous pressure. The drive shaft is capable of absorbing axial and radial loads, enhancing system design flexibility.

4. Through Drive and System Expansion Capability
The A4VSO series supports through drive, allowing direct mounting of subsequent pumps of same or smaller size on the rear of the main pump for single-motor multi-pump compound hydraulic systems. This modular design provides flexibility for system expansion and customization without significant modifications to existing mounting foundations. The through-drive shaft specification and torque capacity must be matched to the power requirements of the subsequent pump.

5. Short Control Response Time and Excellent Suction Characteristics
The A4VSO control mechanism features short response times, with control spool and servo piston area ratios and spring rates precisely matched to ensure fast and stable displacement adjustment. Optimized suction flow passages provide excellent self-priming characteristics, reducing cavitation risk and aeration damage.

Application Areas

Metallurgical Equipment: Continuous casting machine hydraulic systems, rolling mill hydraulic screwdown devices, steelmaking furnace hydraulic power sources
Forging Equipment: Open-die forging presses, closed-die forging press main hydraulic pumps
Mining & Tunneling: Tunnel boring machine thrust hydraulic systems, mine hoist hydraulic drives
Cement & Building Materials: Roller press hydraulic systems, vertical mill hydraulic loading devices
Marine & Offshore: Deck machinery hydraulic systems, large steering gear hydraulic power units
Test Equipment: Large hydraulic test benches, fatigue testing machine hydraulic power sources
Power Generation: Turbine bypass system hydraulic actuators, hydro turbine governor hydraulic systems

Expert Maintenance Tips

1. Hydraulic Fluid Cleanliness
The A4VSO series DR pressure control spool operates with extremely tight clearances and is highly sensitive to particulate contamination. System fluid cleanliness must meet ISO 4406 18/15/12 or better. Install a 10 μm absolute-rated filter element at the pump inlet. Replace elements at 500 hours after first commissioning, then every 1,000 operating hours or 6 months, whichever comes first.

2. DR Pressure Controller Setting and Adjustment
Set the DR pressure controller 15–20 bar above the maximum working load pressure, never exceeding the 350 bar nominal pressure. Adjust only with the system at zero load. Rotate the adjustment screw slowly and verify stable pressure gauge readings before proceeding. Notice: The pressure controller is not a safeguard against pressure overload. A pressure relief valve must be installed in the hydraulic system. Never adjust the controller while the system is under pressure.

3. Case Drain Line Requirements
The case drain line must return directly to the reservoir. Maximum permissible back pressure is 2 bar (0.2 MPa). The drain outlet must terminate below oil level at all times to prevent air ingestion. The drain line diameter must not be smaller than the pump case drain port size. For 250 cc class large displacement pumps, case drain flow is substantial — drain line design must fully account for flow demand to avoid excessive case pressure from pipe resistance.

4. Pre-Start Priming and Air Bleeding
Before first start, fill the pump housing with clean hydraulic fluid through the case drain port. After installation, turn the drive shaft by hand several revolutions to confirm free rotation without binding. Start at low speed with zero load and run for 5–10 minutes. Verify continuous bubble-free flow from the case drain. Only then apply load.

5. Through Drive End Maintenance
If equipped with through drive, regularly inspect rear pump mounting bolt tightness and spline connection wear. The through-drive end bearing is lubricated by the pump’s internal case drain circuit — no additional maintenance required. However, the rear pump’s power demand must not exceed the through-drive rated torque capacity. Inspect through-drive end bolt torque at 500 hours after first commissioning, then recheck every 2,000 operating hours.
