F12-080 Parker Bent Axis Piston Pump/Motor 80.4cc 450bar

Model Number	F12-080-MF-IV-K-000-L130-P0, F12-080

Product Description

Product Overview

The Parker F12-080 is a Parker Hannifin F12 series bent-axis fixed-displacement axial piston pump/motor (compatible with the F11 series), featuring a patented spherical piston design and gear synchronization for open and closed circuit high-speed, high-pressure applications. With a displacement of 80.4 cm³/rev, continuous operating pressure up to 450 bar, and continuous speeds up to 5100 rpm, it offers exceptional overall efficiency and power-to-weight ratio. Our F12-080-MF-IV-K-000-L130-P0 and companion models such as F12-040 and F12-080 are manufactured to original technical specifications, providing 100% interchangeability (flange, shaft end, and port positions fully match OEM) and 100% simulated-duty testing. They deliver reliable performance under high-speed, high-pressure, and heavy-duty conditions as cost-effective direct replacements for genuine Parker F12 units.

Technical Specifications

Model: F12-080-MF-IV-K-000-L130-P0 (series also available in F12-040, F12-060, F12-080, etc.)
Displacement: 80.4 cm³/rev
Continuous pressure: up to 450 bar
Intermittent/peak pressure: up to approx. 480–500 bar (short duration)
Maximum continuous speed: 5100 rpm
Maximum intermittent speed: approx. 5300–5500 rpm
Minimum continuous speed: 50 rpm
Maximum flow: approx. 410 L/min (theoretical)
Theoretical torque at 100 bar: approx. 127.6 Nm
Maximum output power: approx. 308 kW (theoretical)
Control: Fixed displacement (usable as pump or motor, bidirectional)
Shaft example: Metric keyed or splined (K indicates keyed shaft in code)
Approx. weight: 25.7 kg
Design: Bent-axis fixed-displacement piston pump/motor for open and closed circuits

Key Technical Advantages

Patented spherical piston and gear synchronization design deliver the highest overall efficiency, excellent starting torque, smooth operation, and outstanding power-to-weight ratio.
Supports very high continuous speeds (5100 rpm) and pressures (450 bar continuous), ideal for high-speed indirect drives and heavy-duty applications with long service life and high reliability.
Compact construction and optimized sealing provide low noise and strong resistance to thermal shock, with flexible use in both open and closed circuits.
Full dimensional and performance interchangeability plus rigorous simulated-duty testing guarantee drop-in replacement of original Parker units, minimizing downtime and lifecycle costs.

Application Areas

Suitable for construction equipment, forestry machinery, agricultural machinery, mining equipment, marine and offshore applications, municipal vehicles, and industrial hydraulic systems requiring high speed, high pressure, and compact design. Typical uses include excavators, loaders, crushers, fan drives, winches, conveyor systems, and various high-speed open/closed-circuit transmissions.

Expert Maintenance Tips

Verify exact match of mounting flange (ISO/SAE), shaft end (keyed or splined), and port orientation before installation; avoid forced assembly that can damage seals or bearings.
Maintain hydraulic fluid cleanliness to ISO 20/18/13 or better; recommended viscosity 15–30 cSt (allowable range 8–1000 cSt); regularly check case drain pressure and temperature.
When used as a pump, observe self-priming speed limits; when used as a motor, monitor minimum speed and flow to prevent cavitation.
Use matching filter elements and seals during service; record operating pressure and speed profiles to detect early efficiency decline.

3781503 F12-110-LF-IV-D-000-0000-P0
3786220 F12-110-LF-IV-K-000-0000-P0
3721511 F12-110-LS-SV-S-000-0000-P0
3781507 F12-110-LS-SV-T-000-0000-P0
3721946 F12-110-LS-SV-T-000-0000-PT
3785662 F12-110-MF-CV-C-000-0000-P0
3788161 F12-110-MF-CV-K-000-0000-P0
3783407 F12-110-MF-IV-D-000-0000-P0
3721600 F12-110-MF-IV-D-512-L130-P0
3786277 F12-110-MF-IV-K-000-0000-P0
3720074 F12-110-MF-IV-K-000-0000-PT
3785180 F12-110-MF-IV-K-507-L250-P0
3789747 F12-110-MF-IV-K-520-L000-P0
3785731 F12-110-MF-IV-Z-000-0000-P0
3722901 F12-110-MS-SV-D-000-0000-PT
3781549 F12-110-MS-SV-S-000-0000-P0
3721472 F12-110-MS-SV-S-000-0000-PT
3781553 F12-110-MS-SV-S-258-0000-P0
3781555 F12-110-MS-SV-S-505-L130-P0
3720684 F12-110-MS-SV-S-505-L130-PT
3786862 F12-110-MS-SV-T-000-0000-P0
3721125 F12-110-MS-SV-T-000-0000-PT
3723950 F12-110-MU-SV-S-000-0000-P0
3781557 F12-110-RF-IV-D-000-0000-P0
3781558 F12-110-RF-IV-K-000-0000-P0
3722412 F12-110-RF-IV-Z-000-0000-P0
3781563 F12-110-RS-SV-S-000-0000-P0
3723272 F12-110-RS-SV-S-000-0000-PT
3781564 F12-110-RS-SV-T-000-0000-P0
3721126 F12-110-RS-SV-T-000-0000-PT
3782532 F12-110-XF-IV-K-291-0000-P0
3786924 F12-125-LF-IV-K-000-0000-P0
3721500 F12-125-LS-SV-S-000-0000-P0
3789777 F12-125-LS-SV-T-000-0000-P0
3786673 F12-125-MF-CV-B-000-0000-P0
3786814 F12-125-MF-CV-C-000-0000-P0
3721665 F12-125-MF-CV-K-000-0000-P0
3722303 F12-125-MF-CV-X-417-0000-PT
3786589 F12-125-MF-IV-D-000-0000-P0
3786268 F12-125-MF-IV-D-000-0000-PT
3785717 F12-125-MF-IV-K-000-0000-P0
3721774 F12-125-MF-IV-K-000-0000-PT
3724122 F12-125-MF-IV-K-397-0000-PX
3720881 F12-125-MF-IV-K-508-0000-PX
3723255 F12-125-MF-IV-Z-000-0000-P0
3721524 F12-125-MS-SV-D-000-0000-PT
3785819 F12-125-MS-SV-S-000-0000-P0
3787255 F12-125-MS-SV-S-000-0000-PT
3786678 F12-125-MS-SV-T-000-0000-P0
3721679 F12-125-MS-SV-X-418-0000-PT
3720812 F12-125-MU-IV-D-000-0000-PT
3721477 F12-125-MU-SV-T-000-0000-PT
3721959 F12-125-RF-IV-D-000-0000-PT
3786651 F12-125-RF-IV-K-000-0000-P0
3723273 F12-125-RS-SV-S-000-0000-PT
3724170 F12-125-RS-SV-T-000-0000-P0
3724172 F12-152-LA-IV-K-000-0000-P0
3721676 F12-152-LF-FV-G-000-0000-P0
3723796 F12-152-LF-SV-F-000-0000-P0
3721344 F12-152-LF-SV-S-000-0000-P0
3722049 F12-152-MA-SV-S-000-0000-PT
3722153 F12-152-MD-IV-D-000-0000-P0
3721381 F12-152-MD-IV-Z-000-0000-P0
3721294 F12-152-MF-FV-G-000-0000-P0
3721655 F12-152-MF-FV-H-000-0000-P0
3722464 F12-152-MF-FV-X-480-0000-P0
3721348 F12-152-MF-IV-D-000-0000-P0
3721673 F12-152-MF-IV-K-000-0000-P0
3721342 F12-152-MF-SV-G-000-0000-P0
3721144 F12-152-MF-SV-S-000-0000-P0
3722814 F12-152-MF-SV-S-000-0000-PT
3720978 F12-152-MF-SV-T-000-0000-P0
3721377 F12-152-MF-SV-T-000-0000-PT
3724773 F12-152-MF-SV-Z-000-0000-PT
3722762 F12-152-MK-IV-D-000-0000-P0
3721956 F12-152-MK-IV-D-397-0000-PX
3722058 F12-152-MK-SV-F-000-0000-P0
3724417 F12-152-MM-SV-T-000-0000-PT
3724075 F12-152-RA-IV-K-000-0000-P0
3721343 F12-152-RF-FV-G-000-0000-P0
3721795 F12-152-RF-IV-K-000-0000-P0
3724405 F12-152-RF-IV-P-000-0000-P0
3720845 F12-152-RF-SV-S-000-0000-P0
3720633 F12-152-RF-SV-T-000-0000-P0
3720501 F12-152-SF-FV-G-000-0000-P0
3720502 F12-152-SF-FV-H-000-0000-P0
3721703 F12-152-SF-IV-G-000-0000-P0
3721114 F12-152-SF-SV-F-000-0000-P0
3720954 F12-152-SF-SV-G-000-0000-P0
3720839 F12-152-SF-SV-S-000-0000-P0
3720529 F12-152-SF-SV-S-000-0000-PT
3720969 F12-152-SF-SV-T-000-0000-P0
3722848 F12-162-MD-IV-D-000-0000-P0
3724105 F12-162-MD-IV-P-000-0000-P0
3722363 F12-162-MD-IV-Z-000-0000-P0
3721364 F12-162-MF-IV-D-000-0000-P0
3722188 F12-162-MF-IV-K-000-0000-P0
3721373 F12-162-MF-IV-Z-000-0000-P0
3721255 F12-162-MF-SV-S-000-0000-P0
3721253 F12-162-MF-SV-T-000-0000-P0
3721664 F12-162-MK-SV-S-000-0000-P0
3721107 F12-162-MM-IV-Z-000-0000-P0
3722507 F12-162-RF-IV-K-000-0000-P0
3720803 F12-162-RM-IV-P-000-0000-P0
3720411 F12-162-SF-SV-T-000-0000-P0
3721941 F12-182-LF-FV-G-000-0000-P0
3722087 F12-182-MA-IV-K-000-0000-P0
3720618 F12-182-MA-SV-S-000-0000-P0
3721110 F12-182-MD-IV-D-000-0000-P0
3721045 F12-182-MF-FV-D-000-0000-P0
3721438 F12-182-MF-IV-D-000-0000-P0
3721435 F12-182-MF-IV-K-000-0000-P0
3722537 F12-182-MF-IV-Z-000-0000-P0
3724799 F12-182-MF-SV-F-000-0000-PT
3721252 F12-182-MF-SV-S-000-0000-P0
3722299 F12-182-MF-SV-S-000-0000-PT
3721251 F12-182-MF-SV-T-000-0000-P0
3723037 F12-182-MF-SV-T-000-0000-PT
3721833 F12-182-MK-FV-D-000-0000-P0
3723762 F12-182-MK-IV-D-000-0000-P0
3721230 F12-182-MK-IV-K-000-0000-PT
3721812 F12-182-MK-SV-F-000-0000-P0
3721663 F12-182-MK-SV-S-000-0000-P0
3721249 F12-182-MM-IV-K-000-0000-P0
3721355 F12-182-RF-IV-K-000-0000-P0
3724822 F12-182-RF-SV-T-000-0000-P0
3721470 F12-182-RM-SV-S-000-0000-P0
3720333 F12-182-SF-SV-S-000-0000-P0
3720413 F12-182-SF-SV-T-000-0000-P0
3721696 F12-182-SK-IV-K-000-0000-P0
3721188 F12-182-SM-SV-S-000-0000-P0
3788454 F12-250-LF-SV-K-000-0000-P0
3722341 F12-250-LF-SV-S-000-0000-P0
3789250 F12-250-QF-SV-D-000-0000-P0
3789242 F12-250-QF-SV-F-000-0000-P0
3723780 F12-250-QF-SV-F-000-0000-PT
3788847 F12-250-QF-SV-K-000-0000-P0
3722386 F12-250-QF-SV-K-000-0000-PT
3788838 F12-250-QF-SV-S-000-0000-P0
3789576 F12-250-QF-SV-T-000-0000-P0
3788455 F12-250-RF-SV-K-000-0000-P0
