F12-110-MS-SV-S-000-000-P0 Parker Hydraulic Motor 110cc 480bar

Model Number	F12-110-MS-SV-S-000-000-P0, F12-250-QF-SV-F-000-0000-P0

Product Description

Product Overview

The F12 series is a member of the Parker F11/F12 large-frame bent-axis fixed displacement axial piston motor family. The F12 series shares the same 40° bent-axis design philosophy as the F11 series, featuring unique spherical pistons with laminated piston rings, and offers displacements from 30 cc/rev to 250 cc/rev. F12 motors are fixed displacement units that can be used as either motors or pumps in both open and closed-loop circuits.

The F12 series delivers maximum intermittent operating pressures up to 480–500 bar and continuous operating pressures up to 420 bar, with speeds up to 7,300 rpm. Core design features include precision gear synchronization and heavy-duty roller bearings, providing exceptional vibration resistance and high radial load capacity. The 7 or 9-piston design provides high starting torque and smooth motor operation.

Our product provides a fully interchangeable direct replacement for the original Parker F12 series motor, with identical mounting dimensions, port specifications, and shaft configurations. Every unit undergoes 100% simulated duty-cycle testing—performance-validated under rated pressure, peak pressure, and full speed range to ensure volumetric efficiency, mechanical efficiency, torque output, noise levels, and thermal characteristics meet or exceed original OEM specifications.

Model 1: F12-110-MS-SV-S-000-000-P0

Technical Specifications

Full Model: F12-110-MS-SV-S-000-000-P0
Material Number: 3781549
Brand: Parker Hannifin
Series: F12 Large Frame Series
Type: Bent-Axis Fixed Displacement Axial Piston Motor
Displacement: 110.1 cm³/rev
Max. Intermittent Pressure: 480 bar (6,960 psi)
Max. Continuous Pressure: 420 bar (6,090 psi)
Max. Intermittent Speed: 4,800 rpm
Max. Continuous Speed: 4,400 rpm
Min. Continuous Speed: 50 rpm
Theoretical Torque @ 100 bar: 174.8 Nm
Max. Input Flow: 484 L/min (continuous)
Max. Drain Oil Temperature: 115°C
Min. Ambient / Oil Temperature: -40°C
Mass Moment of Inertia: 11.2 × 10⁻³ kg·m²
Radial Load Capacity: 1,900 kg (4,180 lb)
Max. Noise Level: 80 dBA
Mounting Flange: SAE 4-Bolt Flange
Shaft: SAE Splined Shaft (13Z-16/32)
Connection: SAE 6000 psi Flange Ports
Seals: FKM (Fluorocarbon Rubber) High-Temperature
Housing Material: High-Strength Cast Iron
Weight: Approx. 33–36 kg

Key Technical Advantages

1. 40° Bent-Axis Design with Spherical Pistons
The F12 series features Parker’s signature 40° bent-axis design with unique spherical pistons and laminated piston rings. The 40° angle between the drive shaft and cylinder barrel delivers a compact, lightweight structure with an excellent power-to-weight ratio. The spherical piston design significantly reduces internal leakage, improves volumetric efficiency, and provides excellent thermal shock resistance.

2. Gear Synchronization & Heavy-Duty Roller Bearings
Precision timing gears ensure exact phase synchronization between shaft and cylinder barrel, providing exceptional tolerance to high G-forces and torsional vibrations. Heavy-duty roller bearings deliver radial load capacity up to 1,900 kg and support substantial external axial and radial shaft loads.

3. High Pressure & High Speed Capability
The F12-110 delivers maximum intermittent pressure of 480 bar and continuous working pressure of 420 bar. Maximum continuous speed reaches 4,400 rpm and intermittent speed reaches 4,800 rpm. The combination of high pressure and high speed provides exceptional power density in a compact package.

4. Low Internal Leakage & High Efficiency
Laminated piston rings minimize internal leakage while delivering high overall efficiency. The 7 or 9-piston design provides high starting torque and smooth motor operation. The simple, direct design with few moving parts makes the F12 series exceptionally reliable.

5. Compact Design & Wide Temperature Range
Compact housing with excellent power-to-weight ratio. Operating temperature range from -40°C to +115°C enables reliable performance in both extreme cold and high-temperature environments.

Application Areas

The F12-110-MS-SV-S-000-000-P0 is widely used in drive systems across heavy construction and industrial equipment:

High-Speed Saw Drives: Chain saws, circular saws
Forestry Machinery: Feller bunchers, skidders, forwarders
Construction Equipment: Skid-steer loaders, off-highway trucks
Marine Machinery: Marine deck cranes, constant tension winches, hatch covers
Oil & Gas: Nitrogen pumpers, frac trucks, coil tubing equipment
Industrial Equipment: Fan drives, dust collectors, aircraft test stands
Lifting Equipment: Crane swing and winch drives

Expert Maintenance Tips

Shaft seals and all O-rings must be replaced after every disassembly.
Pre-lubricate all moving parts with clean hydraulic fluid before assembly.
Purge all air from the motor housing before initial start-up—ensure the case drain line returns directly to the reservoir with the outlet below the oil level to prevent air entrapment and bearing starvation.
Recommended maximum system operating temperature should not exceed 80°C; drain oil temperature should not exceed 115°C.
Monitor case drain flow regularly—an abnormal increase indicates potential piston ring or cylinder barrel wear.
Ensure hydraulic system filtration meets β₁₀ ≥ 75 (ISO 4406 cleanliness code不低于 18/16/13) to maximize motor service life.
Weight is approx. 33–36 kg—use proper handling procedures during installation and removal.
The F12-110 features SAE 6000 psi flange ports and SAE 4-bolt flange—ensure port sealing surfaces are clean and undamaged during installation.

Model 2: F12-250-QF-SV-F-000-0000-P0

Technical Specifications

Full Model: F12-250-QF-SV-F-000-0000-P0
Material Number: 3789242
Brand: Parker Hannifin
Series: F12 Large Frame Series
Type: Bent-Axis Fixed Displacement Axial Piston Motor
Displacement: 242 cm³/rev
Max. Continuous Pressure: 350 bar (5,075 psi)
Maximum Pressure: 420 bar (6,090 psi)
Max. Intermittent Pressure: 500 bar (7,251 psi)
Max. Continuous Speed: 2,700 rpm
Max. Intermittent Speed: 3,000 rpm
Min. Continuous Speed: 50 rpm
Max. Continuous Input Flow: 653 L/min
Max. Intermittent Input Flow: 726 L/min
Theoretical Torque @ 100 bar: 384.1 Nm
Max. Drain Oil Temperature: 115°C
Min. Ambient / Oil Temperature: -40°C
Mass Moment of Inertia: 46 × 10⁻³ kg·m² (0.046 kg·m²)
Radial Load Capacity: 1,900 kg (4,180 lb)
Max. Noise Level: 80 dBA
Mounting Flange: SAE 4-Bolt Flange
Shaft: SAE Splined Shaft
Connection: 2 × 1-1/2″ SAE 6000 psi Flange Ports
Seals: FKM (Fluorocarbon Rubber) High-Pressure High-Temperature
Speed Sensor: Prepared for speed sensor installation
Housing Material: High-Strength Cast Iron
Weight: Approx. 77 kg

Key Technical Advantages

1. 40° Bent-Axis Design with Spherical Pistons
As the largest displacement model in the F12 series (242 cc/rev), the F12-250 features Parker’s signature 40° bent-axis design with unique spherical pistons and laminated piston rings. The 40° angle delivers a compact, lightweight structure with an excellent power-to-weight ratio.

2. Large Displacement & Ultra-High Torque Output
With 242 cm³/rev delivering 384.1 Nm theoretical torque at 100 bar. Combined with 420 bar working pressure, the maximum torque output is exceptionally high. Maximum continuous flow reaches 653 L/min and intermittent flow reaches 726 L/min—the highest power-rated model in the F12 series.

3. Gear Synchronization & Heavy-Duty Roller Bearings
Precision timing gears ensure exact phase synchronization between shaft and cylinder barrel. Heavy-duty roller bearings deliver radial load capacity up to 1,900 kg for demanding high-load applications.

4. Broad Application Coverage & Low-Noise Design
The F12-250 is suitable for open and closed-loop circuits. The 7 or 9-piston design provides high starting torque and smooth motor operation. Operating noise ≤ 80 dBA meets industrial noise standards.

5. Speed Sensor Prepared for Smart Monitoring
This model is prepared with a speed sensor interface, facilitating system integration for speed monitoring and closed-loop control.

Application Areas

The F12-250-QF-SV-F-000-0000-P0, as the largest displacement model in the F12 series, is widely used across heavy construction and industrial equipment:

High-Speed Saw Drives: Heavy-duty chain saws, circular saws
Forestry Machinery: Feller bunchers, skidders, forwarders
Construction Equipment: Skid-steer loaders, off-highway trucks
Marine Machinery: Marine deck cranes, constant tension winches, hatch covers
Oil & Gas: Nitrogen pumpers, frac trucks, coil tubing equipment
Industrial Equipment: Fan drives, dust collectors, aircraft test stands

Expert Maintenance Tips

Shaft seals and all O-rings must be replaced after every disassembly.
Pre-lubricate all moving parts with clean hydraulic fluid before assembly.
Purge all air from the motor housing before initial start-up—ensure the case drain line returns directly to the reservoir with the outlet below the oil level to prevent air entrapment and bearing starvation.
Recommended maximum system operating temperature should not exceed 80°C; drain oil temperature should not exceed 115°C.
Monitor case drain flow regularly—an abnormal increase indicates potential piston ring or cylinder barrel wear.
Ensure hydraulic system filtration meets β₁₀ ≥ 75 (ISO 4406 cleanliness code不低于 18/16/13) to maximize motor service life.
Weight is approx. 77 kg—use proper lifting equipment during installation and removal to prevent personal injury or component damage.
The F12-250 features 2 × 1-1/2″ SAE 6000 psi flange ports—ensure port sealing surfaces are clean and undamaged during installation.
This model is prepared for speed sensor installation—consider installing a speed sensor during system integration for closed-loop control and condition monitoring.
