HPLPA217DMLG6G4B00 Bondioli Hydraulic Gear Pump 217cc 200bar

Product Overview

The HPLPA217DMLG6G4B00 is a Bondioli & Pavesi HPL Series (Series L) aluminum-bodied fixed displacement external gear pump. Bondioli & Pavesi, founded in 1950, holds a leading position in the power transmission sector. The company is a globally recognized leader in hydraulic transmission and control technology, with gear pumps renowned for their robust construction, cost-effective price/performance ratio, easy installation, customizable solutions, and the ability to integrate control valves.

The HPL Series features high-strength aluminum bodies and is available in 5 group sizes (Group 0 through Group 4), with displacements ranging from 0.19 cm³/rev to 90 cm³/rev. Operating pressures reach up to 310 bar. The series employs a modular design, enabling multiple pumps to be assembled by combining sections of different units, families, and displacements.

This model, HPLPA217DMLG6G4B00, belongs to the HPL PA2 Group (Group 2) and is a large-displacement specification within the HPL Series. The “217” in the model code indicates a displacement of approximately 21.7 cm³/rev (in HPL Series coding, 217 corresponds to 21.7 cc/rev displacement). Group 2 covers displacements from 4.50 to 40.50 cm³/rev. As an original specification model within the Bondioli & Pavesi HPL line, this product enables direct form-fit-function interchangeability with original Bondioli units—no modifications to piping or mounting interfaces required. Our replacement solution strictly adheres to Bondioli technical standards and undergoes 100% simulated in-service testing to ensure performance, reliability, and service life identical to OEM products.

Technical Specifications

Applicable Model (Primary):

• HPLPA217DMLG6G4B00

Related Models in Series:

• HPLPA114DDDG3G3B00 (Group 1, approx. 114 cc/rev specification)

• HPLPA131DDDG3G3B00 (Group 1, approx. 131 cc/rev specification)

• HPLPA148DDDG3G3E00 (Group 1, approx. 148 cc/rev specification)

• HPLPA180DDEM4M2B00 (Group 1, approx. 180 cc/rev specification)

Model Code Breakdown (per Bondioli & Pavesi naming convention):

• Product Series: HPL — Aluminum Gear Pump

• Group Size: PA2 — Group 2

• Displacement Code: 217 — Approx. 21.7 cm³/rev

• Configuration: DMLG6G4 — Specific flange/shaft/port configuration

Series Technical Specifications (per Bondioli & Pavesi official documentation):

• Product Series: Bondioli & Pavesi HPL Aluminum Gear Pump

• Pump Type: Fixed Displacement External Gear Pump

• Body Material: High-Strength Aluminum Alloy

• Mounting: SAE / ISO Standard Flanges

• Fluid Compatibility: Mineral Hydraulic Oil (ISO VG 46)

• Operating Temperature Range: -20°C to +80°C

• Optional Configurations: Aluminum or cast iron flanges, belt drive, external mounts

Group 2 (PA2) Performance Parameters (per Bondioli & Pavesi official documentation):

• Displacement Range: 4.50 – 40.50 cm³/rev

• Continuous Pressure: 140 – 240 bar

• Intermittent Pressure: 160 – 260 bar

• Peak Pressure: 180 – 300 bar

• Maximum Speed: 2,500 – 3,500 min⁻¹

• Minimum Speed: 700 min⁻¹

This Model (HPLPA217) Detailed Specifications (estimated based on Group 2 parameters):

• Geometric Displacement: Approx. 21.7 cm³/rev (model code 217)

• Continuous Operating Pressure: Approx. 200 bar (based on Group 2 range)

• Peak Pressure: Approx. 250 bar

• Maximum Speed: Approx. 2,500 – 3,000 min⁻¹

• Minimum Speed: Approx. 700 min⁻¹

• Theoretical Flow (@2,500 rpm): Approx. 54.3 L/min

• Operating Temperature Range: -20°C to +80°C

• Fluid Compatibility: Hydraulic Oil (ISO VG 46)

• Weight: Approx. 4.0 – 5.0 kg (Group 2, estimated)

Key Technical Advantages

1. High-Strength Aluminum Body — Lightweight Design
The HPL Series features a high-strength aluminum body that delivers excellent performance while significantly reducing overall weight. The lightweight design simplifies installation and is particularly suitable for weight-sensitive mobile equipment and vehicle-mounted hydraulic systems.

2. Modular Design — Flexible Multi-Pump Configurations
The HPL Series employs a modular design, enabling multiple pumps to be assembled by combining sections of different units, families, and displacements. The single pump coding system is clear and straightforward (HPLPA0 | HPLPA1 | HPLPA2 | HPLPA3 | HPLPA4), facilitating selection and configuration. Products can be configured to meet specific machine requirements.

3. High Pressure Capacity
The HPL Series delivers operating pressures up to 310 bar. Group 2 offers 140 – 240 bar continuous pressure and peak pressures up to 300 bar, providing excellent pressure capacity in the aluminum gear pump class.

4. Wide Speed Range — Flexible Adaptation to Diverse Operating Conditions
The HPL Series offers a broad speed range. Group 2 achieves maximum speeds of 2,500 – 3,500 min⁻¹ and minimum speeds as low as 700 min⁻¹. This wide speed range flexibly adapts to diverse application requirements—from low-speed high-torque to high-speed high-flow conditions.

5. Rich Configuration Options with Integration Capabilities
The HPL Series offers options for aluminum or cast iron flanges, belt drive installation, external mounts, and pressure/directional control valves. The modular design enables product configuration to meet specific machine requirements, accommodating diverse system needs.

Application Areas

• Agricultural Machinery: Tractor hydraulic systems, combine harvesters, seeders, fertilizer spreaders

• Construction Equipment: Hydraulic systems for small to medium construction machinery

• Material Handling Equipment: Forklift hydraulic systems, aerial work platforms

• Industrial Hydraulic Systems: Hydraulic power units for industrial equipment

• Hydraulic Steering Systems: Power steering for mobile equipment

• Road Building Machinery: Hydraulic systems for road construction equipment

Expert Maintenance Tips

1. Installation Precautions

• The HPL Series is a uni-directional rotation pump—verify that the system‘s required rotation direction matches the pump’s identification marking before installation.

• Ensure coaxial alignment between the pump and drive shaft; flexible couplings are recommended to avoid radial loads on the pump shaft.

• The suction line diameter must not be smaller than the pump inlet port to prevent cavitation.

• Group 2 pumps are heavier—ensure the mounting bracket has adequate load capacity.

2. Fluid Management

• Use anti-wear hydraulic oils conforming to ISO VG 32 / VG 46 standards.

• System fluid cleanliness must meet Bondioli-recommended standards.

• Operating temperature should be maintained within -20°C to +80°C.

• Prime the pump by filling the housing with hydraulic fluid through the suction port before initial start-up. Never run the pump dry.

3. Start-Up & Commissioning

• Use jog start method for initial start-up; verify correct rotation direction before continuous operation.

• Allow the pump to run under no-load (low pressure) conditions for 2-3 minutes to purge air and ensure proper lubrication.

• Gradually increase to operating pressure while monitoring noise, temperature, and system pressure for normal operation.

4. Routine Maintenance

• The HPL gear pump itself is maintenance-free; however, regular maintenance of the entire hydraulic system is essential for trouble-free pump operation.

• Inspect system fluid cleanliness and condition every 1,000-2,000 operating hours.

• Regularly replace return line filters and suction strainers to prevent contaminant ingress into the pump body.
