HQS26SD63N65T Taiyo HQS2 Compact Hydraulic Cylinder

Product Overview

The HQS, HQS26, 140H, 70H and CDM1MP5 series (specific model HQS26SD63N65T) are Taiyo HQS2 series compact high-pressure hydraulic oil cylinders featuring special aluminum alloy body construction and precision manufacturing for space-constrained high-pressure applications. Fully interchangeable with original Taiyo dimensions and interfaces, they install directly as drop-in replacements without modifying mounts or plumbing. Every unit undergoes 100% simulated operating condition testing to ensure reliable performance under high pressure, vibration and continuous loading, making them ideal for systems requiring high push/pull force and precise control.

Technical Specifications

• Model: HQS26SD63N65T (HQS2 / 140H / 70H / CDM1 related series)
• Bore diameter: φ63 mm (series covers φ20–φ100 mm)
• Stroke: 65 mm (customizable)
• Acting type: Double-acting single rod
• Construction: Compact aluminum alloy body design
• Nominal pressure: Up to 16 MPa (160 bar, depending on operating frequency)
• Piston rod thread: T (male thread)
• Seal system: High-performance wear-resistant seals
• Operating temperature range: –10…+70 °C (standard)
• Test standards: Compliant with Taiyo original specifications and ISO 16656-related standards

Key Technical Advantages

• Lightweight compact high-strength construction: Special aluminum alloy body and special copper alloy bearings deliver high output force and excellent wear resistance within limited space.
• Full interchangeability: Manufactured to exact Taiyo HQS2 and 140H/70H series dimensions and mounting interfaces for true drop-in replacement, minimizing downtime.
• Precision machining and sealing system: Precision-machined tube and hard-chrome plated piston rod combined with wear-resistant seals reduce internal leakage, improve volumetric efficiency and extend service life.
• Rigorous quality control: Every cylinder undergoes 100% simulated duty-cycle testing to verify pressure integrity, leakage and fatigue performance for long-term industrial reliability.

Application Areas

Injection molding machines, die-casting machines, machine tools, automation equipment, test stands, material handling equipment, and industrial hydraulic systems requiring compact high-pressure double-acting push/pull control. Especially suitable for OEM equipment and retrofit projects.

Expert Maintenance Tips
