HPLPA012DAAG2G2B00 Bondioli Hydraulic Gear Pump 1.25cc 310bar

Product Overview

The HPLPA012DAAG2G2B00 is a Bondioli & Pavesi HPL Series (Series L) aluminum-bodied fixed displacement external gear pump. Founded in 1950, Bondioli & Pavesi holds a leading position in the power transmission sector. Its gear pumps are renowned for their robust construction, cost-effective price/performance ratio, easy installation, customizable solutions, and the ability to integrate control valves.

The HPL Series features high-strength aluminum bodies and is available in 5 group sizes (Group 0 through Group 4), with displacements ranging from 0.19 cm³/rev to 88 cm³/rev. Operating pressures reach up to 310 bar. The series employs a modular design, enabling multiple pumps to be assembled by combining sections of different units, families, and displacements.

This model, HPLPA012DAAG2G2B00, belongs to the HPL PA0 Group (Group 0) and is a micro-pump specification within the HPL Series. The “012” in the model code indicates a displacement of approximately 1.25 cm³/rev. This pump is the successor to the HLP-DG-0513D and features a 6 mm cylindrical shaft with G1/4″ ports. Group 0 covers displacements from 0.19 to 1.6 cm³/rev and is ideal for precision control and small hydraulic circuits. As an original specification model within the Bondioli & Pavesi HPL line, this product enables direct form-fit-function interchangeability with original Bondioli units—no modifications to piping or mounting interfaces required. Our replacement solution strictly adheres to Bondioli technical standards and undergoes 100% simulated in-service testing to ensure performance, reliability, and service life identical to OEM products.

Technical Specifications

Applicable Model (Primary):

• HPLPA012DAAG2G2B00

• Predecessor: HLP-DG-0513D

Related Models in Series:

• HPLPA114DDDG3G3B00 (Group 1)

• HPLPA131DDDG3G3B00 (Group 1)

• HPLPA148DDDG3G3E00 (Group 1)

• HPLPA180DDDG3G3B00 (Group 3)

Model Code Breakdown (per Bondioli & Pavesi naming convention):

• HPL — Series identifier: Aluminum Standard Gear Pump

• PA — Pump type: PA (Single Pump)

• 0 — Group size: Group 0 (Micro pump)

• 12 — Displacement code: Corresponds to 1.25 cm³/rev

• DA — Mounting flange configuration

• AG2 — Shaft type configuration

• G2 — Inlet port specification

• B00 — Specific configuration code

Series Technical Specifications (per Bondioli & Pavesi official documentation):

• Product Series: Bondioli & Pavesi HPL Aluminum Gear Pump

• Body Material: High-Strength Aluminum Alloy

• Pump Type: Fixed Displacement External Gear Pump

• Displacement Range: 0.19 – 88.0 cm³/rev

• Operating Pressure: 250 bar continuous, 310 bar peak

• Speed Range: 500 – 4,000 rpm

• Volumetric Efficiency: ≥ 95% (at rated conditions)

• Operating Temperature: -20°C to +80°C (standard NBR seals); up to +120°C with FKM seals

• Fluid Compatibility: Hydraulic Oil (ISO VG 46)

• Mounting Standards: SAE / ISO Standard Flanges

Group 0 (PA0) Performance Parameters (per Bondioli & Pavesi official documentation):

• Displacement Range: 0.19 – 1.60 cm³/rev

• Application: Precision control, small hydraulic circuits

• Maximum Speed: Approx. 4,000 min⁻¹

This Model (HPLPA012) Detailed Specifications:

• Geometric Displacement: Approx. 1.25 cm³/rev (model code 012)

• Maximum Operating Pressure: 310 bar (peak)

• Maximum Speed: Approx. 4,000 min⁻¹

• Shaft Type: 6 mm Cylindrical Shaft

• Port Size: G1/4″

• Operating Temperature Range: -20°C to +80°C (standard NBR seals)

• Fluid Compatibility: Hydraulic Oil (ISO VG 46)

Key Technical Advantages

1. High-Strength Aluminum Body — Ultra-Lightweight Design
The HPL Series features a high-strength aluminum body that delivers excellent performance while significantly reducing overall weight. The Group 0 micro-pump design makes it particularly suitable for precision hydraulic systems with strict space and weight limitations.

2. Helical Gears with Precision Finishing — Ultra-Low Noise Operation
The HPL Series incorporates helical gears with specialized finishing processes that significantly reduce hydraulic pulsation and noise levels. It is especially recommended for mobile and industrial applications requiring excellent acoustic comfort.

3. Modular Design — Flexible Multi-Pump Configurations
The HPL Series employs a modular design, enabling multiple pumps to be assembled by combining sections of different units, families, and displacements. Products can be configured to meet specific machine requirements.

4. High Pressure Capacity
The HPL Series delivers operating pressures up to 310 bar. The Group 0 micro-pump offers exceptional pressure capacity in its class, making it suitable for precision control systems requiring high-pressure output.

5. Rich Configuration Options with Integration Capabilities
The HPL Series offers options for aluminum or cast iron flanges, belt drive installation, external mounts, and pressure/directional control valves. Diverse system requirements can be accommodated.

Application Areas

• Agricultural Machinery: Compact agricultural implement hydraulic systems, precision seeders

• Construction Equipment: Hydraulic control circuits for small construction machinery

• Hydraulic Steering Systems: Power steering for mobile equipment

• Material Handling Equipment: Small forklifts, lift platform hydraulic systems

• Industrial Hydraulic Systems: Hydraulic power units for precision industrial equipment

• Specialty Vehicles: Municipal vehicle auxiliary hydraulic systems

Expert Maintenance Tips

1. Installation Precautions

• The HPL Series is a uni-directional rotation pump—verify that the system‘s required rotation direction matches the pump’s identification marking before installation.

• This model features a 6 mm cylindrical shaft—ensure precise fit between the shaft and coupling during installation.

• Ensure coaxial alignment between the pump and drive shaft; flexible couplings are recommended to avoid radial loads on the pump shaft.

• The suction line diameter must not be smaller than the pump inlet port (G1/4″) to prevent cavitation.

• Refer to the Bondioli & Pavesi official “Gear pumps and motors Installation and Operation Manual” for proper installation procedures.

2. Fluid Management

• Use anti-wear hydraulic oils conforming to ISO VG 32 / VG 46 standards.

• System fluid cleanliness must meet Bondioli-recommended standards.

• Operating temperature should be maintained within -20°C to +80°C (standard NBR seals).

• Prime the pump by filling the housing with hydraulic fluid through the suction port before initial start-up. Never run the pump dry.

3. Start-Up & Commissioning

• Use jog start method for initial start-up; verify correct rotation direction before continuous operation.

• Allow the pump to run under no-load (low pressure) conditions for 2-3 minutes to purge air and ensure proper lubrication.

• Gradually increase to operating pressure while monitoring noise, temperature, and system pressure for normal operation. Volumetric efficiency should remain at or above 95%.

4. Routine Maintenance

• The HPL gear pump itself is maintenance-free; however, regular maintenance of the entire hydraulic system is essential for trouble-free pump operation.

• Inspect system fluid cleanliness and condition every 1,000-2,000 operating hours.

• Regularly replace return line filters and suction strainers to prevent contaminant ingress into the pump body.
