R928006755 Rexroth Hydraulic Oil Filter Element 10µm

Model Number	R928006647, R928006971, R928006701, R928006755

Product Description

Product Overview

The R928006755 Hydraulic Oil Filter Element Cartridge (cross-compatible with R928006701, R928006971, R928006647, and Mahle PI4145PS25) is a high-efficiency fluid filtration solution engineered for heavy-duty industrial hydraulic systems. Manufactured in strict compliance with Bosch Rexroth technical standards and ISO filtration testing specifications, this cartridge effectively captures micro-particulate contaminants generated by component wear and fluid oxidation. Built with multi-layer inorganic microglass fiber and high-strength galvanized steel support mesh, it offers high dirt-holding capacity, low initial differential pressure, and superior resistance against pressure surges. Every unit is 100% factory-tested for structural integrity and bubble point verification to guarantee 100% drop-in interchangeability, safeguarding high-pressure piston pumps, proportional valves, and servo actuators from premature failure.

Technical Specifications

Full Model Code: R928006755 (Cross-ref: R928006701, R928006971, R928006647, Mahle PI4145PS25)
Filter Media: Multi-layer inorganic Microglass Fiber supported by epoxy-coated mesh
Filtration Rating: 10 µm (Beta ratio $\beta_{10(c)} \ge 1000$ per ISO 16889)
Differential Collapse Pressure: 30 bar (Standard) / 210 bar (High-collapse option)
Rated Flow Capacity: Up to 45 L/min
Flow Direction: Outside to Inside
Seal Material: NBR (Buna-N standard; FKM Fluorocarbon optional)
Operating Temperature Range: -30°C to +100°C (NBR) / -20°C to +120°C (FKM)
Net Weight: Approx. 0.35 kg

Key Technical Advantages

100% Drop-In OEM Interchangeability: Dimensional tolerances for outer/inner diameters, end caps, and O-ring grooves precisely match OEM housing specifications for direct, tool-free replacement.
High Dirt-Holding Capacity & Deep Filtration: Pleated multi-layer gradient glass fiber media captures particles progressively across its depth, significantly extending element service life and reducing maintenance frequency.
Robust Construction Against Pressure Spikes: Corrosion-resistant galvanized steel end caps and inner core bound with epoxy adhesive prevent element collapse or media migration under high pressure surges.
100% Factory Bench Tested & ISO Compliant: Verified via ISO 2941 (collapse resistance), ISO 2942 (fabrication integrity), and ISO 3968 (flow fatigue) testing to guarantee zero fluid bypass and consistent filtration efficiency.

Application Areas

Metallurgy & Steel Mills: High-pressure servo squeeze systems, continuous casting hydraulic circuits, and lubrication stations.
Machine Tools & Injection Molding: Precision CNC hydraulic power packs and injection molding pressure line filtration.
Construction Machinery: Mobile hydraulic power systems, excavator main pump protection, and rotary drilling rigs.
Industrial Power Units (HPU): Wind turbine hydraulic stations, power generation plants, and heavy forging presses.

Expert Maintenance Tips

Monitor Differential Pressure Indicators: Replace the filter element immediately when the clog indicator signals a differential pressure of 2.5 bar to 3.5 bar to prevent bypass valve opening and unfiltered fluid circulation.
Clean Housing Prior to Installation: Drain trapped oil completely from the filter bowl and clean internal surfaces with fresh flushing fluid to eliminate settled sediment before installing the new cartridge.
Pre-Lubricate Seals for Smooth Fit: Apply a light coat of clean hydraulic oil to the end cap O-ring before inserting the element into the housing. Push firmly along the center axis to prevent seal pinching or shear damage.
