Samhydraulik Brevini M6 M7 Series Motor | M6V3N1C2A0A00 High Pressure Hydraulic Motor

Genlu Hydraulic proudly introduces our industrial and mobile fleet grade M6 and M7 Series (comprehensively encompassing M6F, M6G, M6V, M7, and M7G frame matrix evolutions) high-pressure axial piston hydraulic motors. This series is fully engineered as a seamless, high-value, drop-in replacement for the classic Brevini (Samhydraulik) M6/M7 series high-pressure fixed and variable piston motors, adapting flawlessly to intricate fluid distribution configurations and shaft interfaces such as M6V3N1C2A0A00 and M6F2N1D3. Serving as the primary dynamic drive component for planetary crawler gearboxes, heavy-duty hoist winch drums, rotary drilling rigs power heads, and high-frequency vehicle vibratory circuits, this series utilizes a compact swashplate axial piston framework delivering excellent power density and high-speed carrying performance. Genlu guarantees 100% Drop-in Interchangeability across standard SAE/ISO mounting configurations, involute splined drive shafts, rear port centerlines, and fastener threads compared to original Brevini / Samhydraulik benchmarks. Every single high-pressure motor undergoes a rigid 100% simulation test reflecting high-speed, high-pressure dynamic operational field parameters to guarantee outstanding volumetric performance and torque transmission.

Technical Specifications

• Product Series: Brevini Samhydraulik M6 / M7 Series Heavy Duty Axial Piston Hydraulic Motors

• Specific Identification Code: M6V3N1C2A0A00

• Base Framework Designation: M6V Series (Configured with dedicated variable or fixed modular options housing)

• Geometric Displacement Envelope: Covering 20 cc/rev to 75 cc/rev profiles (defined precisely via the third-digit designation “3” relative to specific block profiling)

• Nominal Circuit Operating Pressure: 35.0 MPa (350 bar)

• Peak Transient Circuit Pressure: 40.0 MPa (400 bar)

• Max Continuous Operational Velocity: Up to 4000 rpm to 4500 rpm (ensuring smooth operation in high-frequency circuits)

• Starting Torque Efficiency Curve: $\ge 92\%$ (realized consistently across rated differential pressures)

• Drive Shaft Identification: Standard SAE Involute Splined Shaft Interface (such as configuration code C2 defining specific tooth metrics and pressure angle)

• Case Drain Orientation: Equipped with dual auxiliary drainage paths to handle different horizontal or inverted chassis layouts

Key Technical Advantages:

• High-Compression Damped Swashplate Rotating Assembly: The core 9-piston rotating elements and cylinder block barrel within the M6V3N1C2A0A00 are micro-finished via micrometer-grade cross-grinding. The swashplate sliding surfaces implement a proprietary high-grade anti-wear alloy compound cladding, meaning it effortlessly dampens hydraulic fluid shocks and sustains peak volumetric indexes under a continuous 400 bar alternating peak pressure field.

• Bimetallic Monoblock Vacuum-Sintered Valve Plate: The structural face of the valve plate goes through a vacuum bimetallic bronze-sintering process, infused with high-lead sliding copper elements and customized pre-opening fluid relief notches. This layout limits dangerous fluid-shear noise profiles and localized friction heat when speeding past $4000\text{ rpm}$, shielding the running boundaries against seizure.

• Anti-Vibration Heavy-Load Overhung Shaft Bearings: The main drive shaft is secured by premium rolling bearings rated to counter external cantilever axial and radial vector forces commonly generated at the input stage of planetary wheel/crawler reduction gearboxes. Under sustained maximum velocity schedules, the output shaft maintains impeccable dimensional accuracy and low run-out boundaries.

• Modular Back-Cover Manifold Adaptability (A0A00): The rear port orientation utilizes the compact A0A00 structural configuration, maintaining a short and light envelope while preserving adequate interface space. It readily accommodates supplementary dual anti-shock crossover reliefs, shuttle spools, or mechanical parking brake-release sequencing blocks based on system demands.

Application Areas:

• Heavy Duty Crawler Undercarriage & Slewing Drives: Input drive motors for planetary track travel reducers, structural turntable rotation gears for excavators and rotary piling rigs, and closed-loop HST propulsion drives for specialty vehicles.

• Industrial Hoisting & Heavy Offshore Deck Winches: Primary hoist motors for high-capacity mobile cranes, marine mooring windlasses, and drilling platform heavy spooling winch systems.

• Material Processing & Mobile Tracked Crushers: Core tracking and conveyor drives for heavy-duty crushing and screening plants, and direct mixing drum drives for transit concrete trucks.

Expert Maintenance Tips:

• Enforce Pre-Start Case Fluid Flooding (Non-Negotiable Lifetime Rule): As an ultra-high-speed piston component, the sliding boundaries inside the M6V3N1C2A0A00 demand immediate lubrication before torque application. Once secured into the circuit, fully flood the casing cavity with fresh, filtered hydraulic fluid via the highest physical case drain port until it vents out. Never dry-crank the unit; a lack of boundary oil will cause instantaneous catastrophic scoring of the piston heads within moments of startup.

• Maintain Rigid Low-Pressure Casing Drainage Routes: During circuit runtime, the casing leakage line must drain independently and directly back to the reservoir, discharging safely below the static fluid line. Keep continuous internal case backpressures strictly beneath a maximum of $<0.2\text{ MPa}$. Tying this drain path into pressurized main return lines or filter lines will rapidly blow out the front shaft lip seal, initiating severe external oil loss.

• Deploy Anti-Cavitation Makeup Protection in Inertial Deceleration Loops: If the directional control valve is abruptly returned to neutral while running high-inertia winches or fast crawler assemblies, vehicle momentum transforms the motor into a high-speed pump. If the A/B fluid lines lack responsive anti-cavitation check valves or proper boost replenishment paths, a severe localized vacuum will lock onto the intake chambers, pitting the cylinder bronze cladding through cavitation.
