061B810466 Danfoss MBC8100 Temperature Switch 70-120°C SPDT

Product Overview

The 061B810466, 061B810166, 061B801766, 061B800966, 061B800866, and 061B800366 are modular temperature switches (thermostats) from Danfoss’ MBC 8100 series. The MBC 8100 series is specifically designed for severe industrial and marine applications where compact space and operational reliability are the most critical requirements.

The MBC 8100 temperature switch converts temperature signals into electrical switching signals for temperature alarming, system shutdown, temperature control, and diagnostics. Depending on the model configuration, the sensing element can be either a rigid sensor or a remote bulb. The rigid sensor (Ø13 × 50 mm) can be directly inserted into standard thermowells on process piping or equipment. The remote bulb connects via a 2m armored capillary tube, suitable for applications where the sensor and switch body need to be installed separately.

MBC temperature switches are a core component of Danfoss’ modular block system, designed to withstand high vibration and extreme temperatures in harsh environments such as ship engine rooms. The MBC 8100 series holds all major international marine approvals, making it the preferred solution for temperature monitoring and control in marine and offshore applications.

As a direct replacement solution for the Danfoss MBC 8100 series, this product strictly complies with Danfoss MBC 8000 / MBC 8100 technical standards and offers complete interchangeability—direct drop-in replacement without any modification to mounting dimensions or electrical connections. Every unit undergoes 100% simulated duty cycle testing prior to shipment, ensuring performance reliability and long-term operational stability under actual working conditions.

Technical Specifications

061B810466 (MBC8100-2431-1A02000)

• Model: 061B810466

• Specification Key: MBC8100-2431-1A02000

• Series: MBC 8100

• Product Type: Temperature Switch / Thermostat

• Temperature Range: 70 – 120 °C

• Max. Sensor Temperature: 220 °C

• Ambient Temperature Range: -40 °C to +70 °C

• Differential (Fixed) : 5 K

• Reset Function: Automatic

• Contact Function: SPDT

• Contact Rating: AC15 = 0.5 A, 250 V / DC13 = 12 W, 125 V

• Sensor Type: Remote Bulb

• Sensor Dimensions (Ø × L) : 13 × 50 mm

• Min. Sensor Pocket Length: 65 mm (2 9/16 in)

• Capillary Tube Length: 2000 mm (2 m)

• Armoring: Armored

• Connection to Pocket/Piping: M 18 × 1.5

• Electrical Connection: DIN plug, Pg 11

• Electrical Connection Standard: EN 175301-803-A

• Electrical Specification Standard: EN 60947-5

• Enclosure Rating: IP65

• Charge Type: Adsorption

• Net Weight: 0.384 kg

• Gross Weight: 0.754 kg

• EAN: 5702423213467

• Approvals: ABS, BV, CCC, CCS, CE, DNV, EAC, GL, KRS, LR, LVD, NKK, RINA, RMRS

• Packaging Quantity: 6 pc

061B810166 (MBC8100-1231-1A02000)

• Model: 061B810166

• Specification Key: MBC8100-1231-1A02000

• Series: MBC 8100

• Product Type: Temperature Switch / Thermostat

• Temperature Range: -10 – 30 °C

• Max. Sensor Temperature: 80 °C

• Ambient Temperature Range: -40 °C to +70 °C

• Differential (Fixed) : 3 K

• Reset Function: Automatic

• Contact Function: SPDT

• Contact Rating: AC15 = 0.5 A, 250 V / DC13 = 12 W, 125 V

• Sensor Type: Remote Bulb

• Sensor Dimensions (Ø × L) : 13 × 50 mm

• Min. Sensor Pocket Length: 65 mm (2 9/16 in)

• Capillary Tube Length: 2000 mm (2 m)

• Armoring: Armored

• Connection to Pocket/Piping: M 18 × 1.5

• Electrical Connection: DIN plug, Pg 11

• Electrical Connection Standard: EN 175301-803-A

• Electrical Specification Standard: EN 60947-5

• Enclosure Rating: IP65

• Charge Type: Adsorption

• Net Weight: 0.72 kg

• Gross Weight: 0.748 kg

• EAN: 5702423228775

• Approvals: ABS, BV, CCC, CCS, CE, DNV, EAC, GL, KRS, LR, LVD, NKK, RINA, RMRS

• Packaging Quantity: 6 pc

061B801766 (MBC8100-2611-1A00075)

• Model: 061B801766

• Specification Key: MBC8100-2611-1A00075

• Series: MBC 8100

• Product Type: Temperature Switch / Thermostat

• Temperature Range: 20 – 60 °C

• Ambient Temperature Range: -40 °C to +70 °C

• Reset Function: Automatic

• Contact Function: SPDT

• Sensor Type: Rigid Sensor

• Enclosure Rating: IP65

061B800966 (MBC8100)

• Model: 061B800966

• Series: MBC 8100

• Product Type: Temperature Switch / Thermostat

• Temperature Range: 20 – 60 °C

• Reset Function: Automatic

• Contact Function: SPDT

• Sensor Type: Rigid Sensor

• Enclosure Rating: IP65

061B800866 (MBC8100-2411-1A00075)

• Model: 061B800866

• Specification Key: MBC8100-2411-1A00075

• Series: MBC 8100

• Product Type: Temperature Switch / Thermostat

• Temperature Range: 70 – 120 °C

• Factory Setting: 95 °C (dedicated)

• Max. Sensor Temperature: 220 °C

• Ambient Temperature Range: -40 °C to +70 °C

• Differential (Fixed) : 4 K

• Reset Function: Automatic

• Contact Function: SPDT

• Contact Rating: AC15 = 0.5 A, 250 V / DC13 = 12 W, 125 V

• Sensor Type: Rigid Sensor

• Sensor Dimensions (Ø × L) : 13 × 50 mm

• Min. Sensor Pocket Length: 75 mm (3 in)

• Connection to Pocket/Piping: M 18 × 1.5

• Electrical Connection: DIN plug, Pg 11

• Electrical Connection Standard: EN 175301-803-A

• Electrical Specification Standard: EN 60947-5

• Enclosure Rating: IP65

• Charge Type: Adsorption

• Net Weight: 0.211 kg

• Gross Weight: 0.581 kg

• EAN: 5702428516792

• Approvals: ABS, BV, CCC, CCS, CE, DNV, EAC, GL, KRS, LR, LVD, NKK, RINA, RMRS

• Packaging Quantity: 6 pc

061B800366 (MBC8100-2211-1A00075)

• Model: 061B800366

• Specification Key: MBC8100-2211-1A00075

• Series: MBC 8100

• Product Type: Temperature Switch / Thermostat

• Temperature Range: 50 – 100 °C

• Max. Sensor Temperature: 200 °C

• Ambient Temperature Range: -40 °C to +70 °C

• Differential (Fixed) : 4 K

• Reset Function: Automatic

• Contact Function: SPDT

• Contact Rating: AC15 = 0.5 A, 250 V / DC13 = 12 W, 125 V

• Sensor Type: Rigid Sensor

• Sensor Dimensions (Ø × L) : 13 × 50 mm

• Min. Sensor Pocket Length: 75 mm (3 in)

• Connection to Pocket/Piping: M 18 × 1.5

• Electrical Connection: DIN plug, Pg 11

• Electrical Connection Standard: EN 175301-803-A

• Electrical Specification Standard: EN 60947-5

• Enclosure Rating: IP65

• Charge Type: Adsorption

• Net Weight: 0.218 kg

• Gross Weight: 0.588 kg

• EAN: 5702423232833

• Approvals: ABS, BV, CCC, CCS, CE, DNV, EAC, GL, KRS, LR, LVD, NKK, RINA, RMRS

• Packaging Quantity: 6 pc

Key Technical Advantages

1. Modular Block Design – Engineered for Harsh Conditions
The MBC 8100 series features Danfoss’ unique modular block design, delivering exceptional compactness specifically for space-constrained, high-vibration, severe-environment applications such as ship engine rooms. This design not only saves valuable installation space but also ensures long-term reliability under continuous high-vibration conditions.

2. Comprehensive International Marine Approvals
The MBC 8100 series holds full certifications from virtually all major classification societies worldwide, including: DNV GL, LR (Lloyd’s Register), ABS (American Bureau of Shipping), BV (Bureau Veritas), RINA, NKK (Nippon Kaiji Kyokai), KR (Korean Register), and CCS (China Classification Society) . This core competitive advantage makes MBC 8100 the preferred choice for temperature switches in marine and offshore applications.

3. Two Sensor Options – Flexible Installation
The MBC 8100 series offers both rigid sensor and remote bulb configurations:

• Rigid Sensor: Dimensions Ø13 × 50 mm for direct insertion into standard thermowells. Offers faster thermal response and simpler installation for applications where sensor and switch body are in close proximity.

• Remote Bulb: Connected via a 2m armored capillary tube. Enables separate sensor and switch body installation for space-constrained applications or where the sensor must be located away from electrical connections in high-temperature areas.

4. Fixed Differential – Ensuring Accurate Monitoring
The MBC series features a fixed differential design (3–5 K), factory-set and unaffected by on-site adjustments. This ensures that repeatability remains consistent across the entire setting range, delivering precise and reliable monitoring of critical temperatures.

5. SPDT Contacts & Flexible Electrical Connection
Equipped with SPDT (Single Pole Double Throw) contacts, the switch can be used in either normally open (NO) or normally closed (NC) control circuits to accommodate various control logic requirements. The electrical connection uses a standard DIN plug (Pg 11) per EN 175301-803-A, enabling fast, convenient, and reliable on-site wiring.

6. IP65 Enclosure Rating & Wide Temperature Range
The entire series offers an IP65 enclosure rating for dust-tight and water-jet protection. Ambient temperature range is -40 °C to +70 °C. Whether in cold outdoor environments or high-temperature industrial sites, the MBC 8100 delivers stable and reliable temperature monitoring.

Application Areas

• Marine & Offshore Engineering: Main engine cooling water temperature monitoring and alarm, gearbox oil temperature monitoring, bilge water temperature monitoring, fire-fighting system temperature control

• Diesel Generator Sets: High-temperature alarm and shutdown protection for engine cooling water and lube oil

• Industrial Refrigeration & Air Conditioning Systems: Refrigerant temperature monitoring, condenser temperature control

• Compressors & Power Stations: Compressor oil temperature monitoring, cooling system temperature control

• Factory Monitoring & Alarm Systems: Temperature monitoring and alarming for various process media

• Hydraulic Systems: Hydraulic oil temperature monitoring and cooling system control

• Heating & Hot Water Systems: Boiler outlet temperature control, hot water circulation system temperature monitoring

Expert Maintenance Tips

1. Sensor Installation Position

• Rigid Sensor: Must be fully inserted into the thermowell, ensuring the full sensor length (50 mm) makes good contact with the well. Minimum sensor pocket length is 65–75 mm (model dependent). Fill the well with thermal conductive compound (e.g., thermal grease) to improve heat transfer efficiency and response speed.

• Remote Bulb: The bulb must be fully inserted into the thermowell. The capillary tube (2 m) should be routed without sharp bends or acute-angle kinks—minimum bending radius should be no less than 50 mm.

2. Temperature Setting Procedure
When adjusting the set point, use a dedicated adjustment tool and rotate the setting screw slowly. It is recommended to perform final setpoint calibration under actual system operating temperature and verify the setting 2–3 times to ensure accuracy. Lock the locking nut firmly after setting.

3. Electrical Connection Precautions
Use a mating DIN connector compliant with EN 175301-803-A (Pg 11) for electrical connection. Before wiring, confirm that the supply voltage matches the contact ratings (AC15 0.5 A, 250 V / DC13 12 W, 125 V). Shielded cables are recommended to minimize electromagnetic interference affecting the switch signal.

4. Regular Functional Testing
It is recommended to perform functional testing of the temperature switch every 6 months or during each major system overhaul:

• Simulate temperature rise and verify switch actuation at the set point

• Simulate temperature drop and verify switch reset at the reset point (automatic reset function)

• Inspect DIN connector for loose, oxidized, or arced connections

• Inspect sensor and thermowell connection for damage or corrosion

• Inspect capillary tube (remote bulb models) for damage or wear

5. Installation Torque Specification
For the sensor connection thread (M 18 × 1.5), apply appropriate tightening torque. Prior to installation, inspect the thread for damage and apply an appropriate amount of anti-seize compound to the thread to ensure reliable sealing and facilitate future maintenance disassembly.

6. Seals & Protection
The MBC 8100 series offers IP65 enclosure rating. In humid or salt-spray environments, regularly inspect the sealing condition of the electrical connector to ensure the protection rating remains intact.
