PGP517B0160CD1H3VE6E5S Parker Gear Pump 250bar 16cc

Product Overview

The PGP517B0160CD1H3VE6E5S is an aluminum tandem external gear pump from the Parker Hannifin PGP517 series. This model features two pump sections connected in series, each with a displacement of 16.0 cm³/rev, for a total displacement of 32.0 cm³/rev. It corresponds to Parker part number 3339121186.

Engineered with Parker’s signature three-piece aluminum construction, the pump features pressure-balanced thrust blocks and journal bushings for exceptional durability, high efficiency, and long service life. As a tandem configuration, this pump delivers two independent oil flows from a single drive input, significantly simplifying hydraulic system architecture. This model falls in the mid-displacement range of the PGP517 series (series displacement range 14–70 cm³/rev).

Every unit is manufactured to original equipment specifications, ensuring 100% drop-in interchangeability with genuine Parker PGP517 series pumps without any system modifications. Each pump undergoes rigorous 100% simulated duty-cycle testing on dedicated test benches to validate pressure-flow-efficiency performance curves.

Brand Disclaimer: This product is a high-quality compatible replacement engineered for full interchangeability with Parker Hannifin original equipment. All Parker brand names and model codes are referenced solely to indicate compatibility and interchangeability. This product is manufactured by an independent producer and is not an original Parker product.

Technical Specifications

• Model Code: PGP517B0160CD1H3VE6E5S（full model includes -517A016 suffix）

• Parker Part Number: 3339121186

• Brand Series: Parker Hannifin PGP517 (PGP500 Series)

• Pump Type: Fixed Displacement Gear Pump

• Construction: External gear, three-piece aluminum housing, tandem gear pump

• Primary Section Displacement: 16.0 cm³/rev

• Secondary Section Displacement: 16.0 cm³/rev

• Total Displacement (Both Sections): 32.0 cm³/rev

• Continuous Operating Pressure: 250 bar (25 MPa)

• Peak Pressure: 300–310 bar (30–31 MPa)

• Maximum Speed: 3,400 rpm

• Minimum Speed (Full Pressure): 500 rpm

• Maximum Speed (No Load): 3,400 rpm

• Maximum Flow Rate (Series): 168 L/min

• Rotation Direction: Clockwise (CW) (viewed from drive shaft end)

• Drive Shaft Type: SAE B splined shaft (13T, 16/32DP)

• Mounting Flange: SAE B standard flange

• Housing Material: Aluminum alloy

• Gear Teeth: 13-tooth, high-wear alloy steel, pressure-balanced thrust plates

• Seals: FKM (Fluorocarbon rubber)

• Hydraulic Fluid: Standard hydraulic oil HLP (DIN 51524-2)

• Recommended Viscosity Range: 8–1000 mm²/s

• Operating Temperature Range (FKM seals): -20°C to +105°C

• Recommended Operating Temperature: +15°C to +80°C

• Port Configuration: Side inlet / side outlet

• Inlet Pressure Range: 0.8–2.0 bar (absolute), min. 0.5 bar

• Maximum Pressure Rise Rate: 3,000 bar/s

• Recommended Cleanliness Level: ISO 4406 19/17/13

• Weight: Approx. 20 kg (tandem configuration)

• Noise Level: Approx. 63 dBA @ 2,950 rpm

• Country of Origin: Czech Republic

Key Technical Advantages

1. Lightweight Aluminum Alloy Construction

Featuring Parker’s signature aluminum alloy housing, the pump achieves 30%–50% weight reduction compared to conventional cast iron equivalents. Weighing approximately 20 kg in tandem configuration, it delivers excellent pressure containment at 250 bar continuous rating while significantly reducing overall system weight—ideal for weight-sensitive mobile equipment and aerial lift platforms.

2. Pressure-Balanced Thrust Blocks & Journal Bushings – High Efficiency & Long Life

Integrated pressure-balanced thrust blocks automatically compensate for gear end clearance under high pressure, significantly reducing internal leakage. Paired with journal bushings, friction losses are minimized while extending service life. Volumetric efficiency reaches ≥92%, with overall efficiency ≥85%.

3. Three-Piece Modular Construction & Tandem Configuration Flexibility

The three-piece modular construction supports single, tandem, and multiple pump configurations. This model features a tandem configuration (16+16 cc) with independent displacement per section, enabling simultaneous or separate oil supply for complex hydraulic systems.

4. 13-Tooth Optimized Gear Profile & Low-Noise Operation

The 13-tooth high-wear alloy steel gear pair with optimized tooth profile delivers exceptionally smooth operation. Noise levels are as low as approximately 63 dBA @ 2,950 rpm—making it particularly suitable for cab-near installations and urban equipment operations.

5. Broad Speed & Temperature Operating Range

Supports a wide speed range of 500 to 3,400 rpm with operating temperature range from -20°C to +105°C (FKM seals). Maintains stable flow characteristics from cold start to high-speed continuous duty.

6. Thru-Drive Capability & Multi-Section Expandability

This model features thru-drive capability, allowing tandem connection of additional hydraulic pump sections on the same input shaft. Systems can be flexibly expanded to three or more sections to meet complex multi-circuit hydraulic demands.

7. 100% Simulated Duty-Cycle Testing

Every pump is 100% tested on dedicated hydraulic test benches under simulated real-world operating conditions—validating pressure-flow characteristics and efficiency curves at rated pressure (250 bar), peak pressure (310 bar), and full speed range—ensuring zero-defect, plug-and-play performance upon installation.

Application Areas

• Aerial Lifts: Boom elevation and rotation hydraulic systems

• Agricultural Machinery: Tractor hydraulic systems, combine harvester implement drives

• Construction Equipment: Excavators, loaders, rollers auxiliary hydraulic systems

• Forestry Equipment: Wood processing and material handling equipment

• Material Handling Equipment: Forklifts, telehandler hydraulic systems

• Vocational & Municipal Equipment: Street sweepers, mowers, etc.

• Hydraulic Power Units (HPU): Industrial and mobile power stations

• Power Steering & Brake Systems: Priority valve configurations available

Expert Maintenance Tips

1. Fluid Cleanliness Control

Maintain system fluid cleanliness to ISO 4406 19/17/13 or better. Install a ≤10 μm absolute filtration filter upstream of each inlet port to prevent particle contamination from damaging precision gear pairs, journal bushings, and thrust plates.

2. Inlet Line Requirements

Keep suction lines short and straight with adequate diameter—not less than the port size. Inlet pressure must be maintained between 0.8–2.0 bar (absolute) , with absolute minimum of 0.5 bar. Recommended suction line flow velocity: ≤2.5 m/s. Both inlet ports of the tandem pump must be supplied with sufficient flow independently to prevent cavitation.

3. Coupling Alignment Precision

Flexible couplings are recommended for direct drive. Ensure pump shaft-to-drive shaft coaxiality deviation ≤0.05 mm and angular deviation ≤0.5° during installation. If the drive involves sprockets or V-belt pulleys, an independent outboard bearing MUST be installed to protect pump shaft bearings.

4. First-Start Priming Procedure

Before initial startup, bleed air through both outlet ports or drain ports separately. Perform 2–3 jog starts with outlets open (no load) until oil fills both pump sections without air bubbles, then connect load circuits for full operation.

5. Fluid Temperature Monitoring

Recommended operating temperature range: +15°C to +80°C (FKM seals up to +105°C). During cold starts (-20°C to -15°C), speed must not exceed 1,500 rpm. When viscosity exceeds recommended range during cold starts, ensure adequate suction conditions.

6. Rotation Direction Confirmation

This model is standard configured for clockwise (CW) rotation (viewed from drive shaft end). Always verify that the drive motor/engine rotation matches the pump before installation. Specify counterclockwise (CCW) configuration when ordering if required.
