3726522220 AVENTICS Pressure Reducing Valve 10 bar

Product Overview

⚠️ Brand and Model Note: Verified sources confirm that 3726522220 belongs to the AVENTICS brand, now part of the Emerson group, formerly the Bosch Rexroth pneumatic product line. While some distributors describe this model as a “3/2 solenoid valve”, the user has specified it as part of the 3726/3730/3760/3750 series pneumatic pressure reducing valves. The following content is based on the general specifications of AVENTICS pneumatic pressure reducing valve series.

3726522220 is a pneumatic pressure reducing valve from the AVENTICS 3726/3730/3760/3750 series. This series is widely used in marine main engine remote control systems, offshore engineering pneumatic control systems, and various industrial pneumatic applications for precise pressure regulation and stabilization.

These pneumatic pressure reducing valves feature a modular design with diaphragm-type pressure regulator construction, achieving precise downstream pressure control through dynamic balance between spring force and outlet pressure. The compact valve design supports standard in-line installation for direct integration into pneumatic control panels and piping systems.

Specifically designed for marine and offshore harsh environments, the series features high-strength alloy housing and salt-spray resistant special sealing materials, effectively withstanding engine room heat, humidity, salt spray corrosion, and continuous vessel vibration.

Our complete range of AVENTICS pneumatic pressure reducing valves strictly adheres to OEM technical standards, achieving 100% direct interchangeability with original components. Every unit undergoes 100% simulated operating condition bench testing prior to shipment, ensuring performance parameters are fully consistent with genuine AVENTICS products. Direct replacement significantly reduces equipment downtime and maintenance costs.

Technical Specifications

⚠️ Specification Note: The following are typical technical parameters for AVENTICS 3726/3730/3760/3750 series pneumatic pressure reducing valves. Specific parameters for 3726522220 may vary by configuration code. Please refer to AVENTICS official technical manuals for precise data.

3726/3730/3760/3750 Series General Specifications

• Product Series: AVENTICS 3726/3730/3760/3750 series pneumatic pressure reducing valve

• Model Example: 3726522220

• Brand: AVENTICS / Emerson

• Product Type: Pneumatic Pressure Reducing Valve

• Regulator Type: Diaphragm-type pressure regulator

• Port Connection: G1/4 (typical configuration)

• Operating Pressure Range: 0.5 – 10 bar

• Adjustment Range: 0.5 – 8.5 bar (typical)

• Operating Media: Compressed air

• Ambient Temperature Range: +5°C to +60°C

• Media Temperature Range: +0°C to +60°C

• Mounting Type: In-line piping / Modular combination

• Mounting Orientation: Vertical (recommended)

• Ingress Protection: IP67 (typical configuration)

• Body Material: High-strength alloy

• Seal Material: Salt-spray resistant special seals

• Design Features: Modular construction, combinable as air preparation unit

Key Technical Advantages

1. Marine-Grade Design for Harsh Ocean Environments

AVENTICS 3726/3730/3760/3750 series features high-strength alloy housing and salt-spray resistant special sealing materials, effectively withstanding engine room heat, humidity, salt spray corrosion, and continuous vessel vibration. This series is widely used in marine main engine remote control systems, fuel emergency shutdown, and pneumatic safety circuits.

2. Modular Design for Flexible Configuration

This series features modular construction that can be assembled as a complete air preparation unit. Components include filters, pressure control valves, and more for flexible configuration and expansion. Standardized interfaces and mounting dimensions ensure quick installation and easy maintenance.

3. Precise Pressure Regulation for Stable Downstream Operation

Featuring diaphragm-type pressure regulator construction, precise downstream pressure control is achieved through dynamic balance between spring force and outlet pressure. Adjustment range 0.5–8.5 bar with operating pressure range 0.5–10 bar.

4. Wide Temperature Range for Diverse Operating Conditions

Supports ambient temperatures from +5°C to +60°C and media temperatures from +0°C to +60°C. With IP67 ingress protection (typical configuration), reliable operation is ensured in dusty, splash-water, and harsh environments.

5. European Manufacturing with Traceable Quality

AVENTICS products adhere to German pneumatic manufacturing standards, manufactured in Hungary. Product serial numbers are traceable, ensuring quality reliability and traceability.

6. 100% Direct Interchangeability and Simulated Condition Testing

All models strictly adhere to AVENTICS original mounting dimensions and interface standards, enabling direct drop-in replacement of original pressure reducing valves without piping modification or system adjustment. Every unit undergoes 100% simulated operating condition bench testing prior to shipment.

Application Areas

• Marine Main Engine Remote Control Systems: Engine start control, fuel emergency shutdown, ahead/astern pneumatic control circuits

• Marine Fire Safety Systems: Fire dampers, emergency shut-off valve pneumatic actuation

• Deck Auxiliary Machinery: Hatch cover pneumatic actuators, pneumatic locking devices

• Offshore Generator Sets & Platforms: Pneumatic control units

• Industrial Pneumatic Systems: Factory automation, heavy equipment pneumatic control

• Diesel Engine Pneumatic Control: Remote start/stop, safety protection circuits

Expert Maintenance Tips

1. Verify Model and System Compatibility Prior to Installation

AVENTICS 3726/3730/3760/3750 series offers multiple port sizes and pressure range options. Confirm that the selected model’s port size, operating pressure range (0.5–10 bar) , and adjustment range (0.5–8.5 bar) cover system requirements prior to installation.

2. Correct Installation Orientation

This series recommends vertical installation. Observe flow direction markings on the valve body—inlet and outlet must be correctly oriented. Incorrect installation will prevent the valve from functioning properly.

3. Pressure Setting and Commissioning

• Set the outlet pressure via the adjustment knob (clockwise to increase, counterclockwise to decrease)

• Observe the outlet pressure gauge until the target value is reached

• During commissioning, start from low pressure and gradually increase to the set value to avoid pressure shock damaging downstream components

4. Air Quality Management

Pneumatic pressure reducing valves require certain air quality standards. Install filters and coalescing separators upstream of the pressure reducing valve to ensure compressed air is clean, dry, and oil-free, extending valve service life.

5. Ambient Temperature Control

This series supports ambient temperatures of +5°C to +60°C. Operating outside this range may result in reduced regulation accuracy or accelerated seal aging. Appropriate insulation or cooling measures should be taken under extreme temperature conditions.

6. Periodic Maintenance and Inspection

Perform functional checks every 2,000 operating hours or annually: verify outlet pressure stability, adjustment function, and external leakage. If abnormal pressure fluctuation, adjustment failure, or leakage is observed, arrange for servicing or replacement.
