3726560002 3726 3730 3760 3750 AVENTICS Pressure Reducing Valve 10 bar

Product Overview

⚠️ Brand Attribution Note: Verified sources confirm that 3726560002 belongs to the AVENTICS brand. AVENTICS is a globally recognized brand in pneumatic and hydraulic components, now part of the Emerson group. The 3726, 3730, 3760, and 3750 series are integral parts of the AVENTICS pneumatic product line. Note that the original title’s “Pneumatic On-off” description differs from the actual product type—3726560002 is a pneumatic pressure reducing valve, not an on-off valve.

3726560002 is a pneumatic pressure reducing valve from AVENTICS, belonging to the 3726/3730/3760/3750 series product line. This series is widely used for precise pressure regulation and stabilization in pneumatic systems, ensuring downstream equipment receives a constant, reliable operating pressure.

These pneumatic pressure reducing valves feature diaphragm or piston-type control structures, achieving precise downstream pressure control through balanced spring force and outlet pressure. The compact modular design with G1/4 connections enables direct integration into pneumatic control panels and piping systems.

Our complete range of AVENTICS pneumatic pressure reducing valves strictly adheres to OEM technical standards, achieving 100% direct interchangeability with original components. Every unit undergoes 100% simulated operating condition bench testing prior to shipment, ensuring performance parameters are fully consistent with genuine AVENTICS products. Direct replacement significantly reduces equipment downtime and maintenance costs.

⚠️ Model Notes:

• 3726560002: AVENTICS pneumatic pressure reducing valve, G1/4 connection. Refer to AVENTICS official technical documentation for specific pressure ranges.

• 3726 / 3730 / 3760 / 3750: AVENTICS pneumatic product series codes, covering pressure reducing valves, directional valves, and other pneumatic control components.

Technical Specifications

⚠️ Specification Note: The following are typical technical parameters for AVENTICS pneumatic pressure reducing valve series. Specific parameters for 3726560002 and the 3726/3730/3760/3750 series may vary by configuration code. Please refer to AVENTICS official technical manuals or contact our technical engineers for precise data.

3726/3730/3760/3750 Series General Specifications (Typical Values)

• Product Series: AVENTICS 3726/3730/3760/3750 series pneumatic pressure reducing valve

• Model Example: 3726560002

• Brand: AVENTICS / Emerson

• Product Type: Pneumatic Pressure Reducing Valve

• Control Type: Diaphragm/Piston-operated, spring-loaded

• Port Connection: G1/4 (typical configuration)

• Maximum Inlet Pressure: 10 bar (typical)

• Outlet Pressure Adjustment Range: 0.5 – 8 bar (adjustable)

• Flow Coefficient (Cv) : Refer to specific model configuration

• Operating Media: Compressed air, inert gases

• Operating Temperature Range: -10°C to +60°C

• Body Material: Aluminum alloy / Zinc alloy

• Seal Material: NBR

• Mounting Type: In-line piping / Panel mounting

• Weight: Approx. 0.2 – 0.5 kg (model dependent)

Key Technical Advantages

1. Precise Pressure Regulation for Stable Downstream Equipment Operation

AVENTICS 3726/3730/3760/3750 series pneumatic pressure reducing valves feature precision diaphragm or piston-type control structures, achieving stable downstream pressure through dynamic balance between spring force and outlet pressure. Even when inlet pressure fluctuates, outlet pressure remains constant, ensuring pneumatic actuators (cylinders, valves, etc.) receive a stable operating pressure.

2. Compact Modular Design for Space-Saving Installation

This series features a compact modular design with small footprint and lightweight construction, supporting G1/4 standard connections for direct integration into pneumatic control panels and piping systems. Complex piping is eliminated for efficient, compact pneumatic control systems.

3. Excellent Regulation Characteristics and High Reliability

AVENTICS pneumatic pressure reducing valves offer excellent regulation characteristics—high sensitivity, stable pressure, and good repeatability. Valve bodies are manufactured from high-strength aluminum or zinc alloy with high-quality NBR seals, ensuring long-term reliable operation in industrial environments.

4. Wide Temperature and Media Compatibility

This series supports a wide operating temperature range of -10°C to +60°C. Compatible with compressed air and various inert gases, it adapts to diverse applications from general industrial pneumatic systems to specialized industries including food and pharmaceutical.

5. 100% Direct Interchangeability and Simulated Condition Testing

All models strictly adhere to AVENTICS original mounting dimensions and interface standards (G1/4), enabling direct drop-in replacement of original pressure reducing valves without piping modification or system adjustment. Every unit undergoes 100% simulated operating condition bench testing prior to shipment.

Application Areas

• Industrial Pneumatic Systems: Providing stable operating pressure for pneumatic actuators (cylinders, pneumatic motors, etc.)

• Automation Equipment: Pressure control for assembly lines, packaging machinery, and robotic pneumatic systems

• Pneumatic Tools: Precise pressure supply for pneumatic wrenches, grinders, and other tools

• Food & Pharmaceutical Industries: Clean pneumatic system pressure control

• Automotive Manufacturing: Pressure regulation for paint systems and pneumatic fixtures

• Shipbuilding: Pressure control for marine pneumatic equipment

Expert Maintenance Tips

1. Verify Model and System Compatibility Prior to Installation

AVENTICS 3726/3730/3760/3750 series offers multiple port sizes and pressure range options. Confirm that the selected model’s port size (G1/4, etc.) , inlet pressure rating, and outlet pressure adjustment range cover system requirements prior to installation.

2. Correct Installation Orientation

Ensure the flow direction arrow on the valve body is observed during installation—inlet (IN) and outlet (OUT) must be correctly oriented. Incorrect installation will prevent the valve from functioning properly.

3. Pressure Setting and Commissioning

• Loosen the lock nut and slowly rotate the adjustment knob (clockwise to increase pressure, counterclockwise to decrease)

• Observe the outlet pressure gauge until the target value is reached, then tighten the lock nut

• During commissioning, start from low pressure and gradually increase to the set value to avoid pressure shock damaging downstream components

4. Air Quality Management

Pneumatic pressure reducing valves require certain air quality standards. Install filters (F) and coalescing separators upstream of the pressure reducing valve to ensure compressed air is clean, dry, and oil-free, extending valve service life.

5. Periodic Maintenance and Inspection

Perform functional checks every 2,000 operating hours or annually: verify outlet pressure stability, adjustment function, and external leakage. If abnormal pressure fluctuation, adjustment failure, or leakage is observed, arrange for servicing or replacement.
