HDA4446-A-0400-AN1-000 HYDAC Pressure Transmitter 400 bar
| Model Number | HDA4446-A-0250-AN1-000, HDA4446-A-0400-AN1-000, HDA4446-A-0040-AN1-000 |
|---|
Product Description
Product Overview
The HDA4446-A-0040-AN1-000, HDA4446-A-0250-AN1-000 and HDA4446-A-0400-AN1-000 belong to the HYDAC HDA 4400 series of electronic pressure transmitters with M12 electrical connection. Featuring thin-film strain gauge technology on a stainless steel membrane, these sensors provide a standard 4–20 mA output signal. Mechanical interface is G1/4 A and electrical interface is M12×1 4-pole. Fully interchangeable with original HYDAC HDA4446 units, every transmitter undergoes 100% simulated operating-condition testing for precise pressure monitoring in mobile and industrial hydraulic systems.
Technical Specifications
- Model: HDA4446-A-0040-AN1-000 / HDA4446-A-0250-AN1-000 / HDA4446-A-0400-AN1-000 (HDA 4400 series)
- Type: Electronic pressure transmitter (relative pressure)
- Measuring ranges: 40 bar / 250 bar / 400 bar (model-dependent)
- Overload pressure: typically approx. 2 × measuring range (e.g. approx. 800 bar for 400 bar)
- Burst pressure: typically approx. 5 × measuring range (e.g. approx. 2000 bar for 400 bar)
- Accuracy: ≤ ±0.5 % FS typ. (max. ≤ ±1 % FS); BFSL ≤ ±0.25 % FS typ.
- Output signal: 4–20 mA (2-wire)
- Mechanical connection: G1/4 A (ISO 1179-2)
- Recommended tightening torque: 20 Nm
- Electrical connection: M12×1, 4-pole (mating connector not supplied)
- Wetted parts: Stainless steel + FKM seal
- Protection class: IP67 (with correctly mounted mating connector)
- Compensated temperature range: –25 to +85 °C
- Operating temperature range: –25 to +85 °C
- Rise time: ≤ 1–2 ms
- Supply voltage: approx. 8–30 V DC (2-wire)
Key Technical Advantages
- High-precision thin-film strain gauge sensing: Full-bridge thin-film technology on stainless steel membrane delivers high accuracy, low temperature error and excellent long-term stability (drift ≤ ±0.3 % FS/year).
- Convenient and reliable M12 interface: Standard M12×1 4-pole electrical connection offers high protection rating and enables quick field wiring and replacement.
- True interchangeability and robust construction: Fully compatible with original HYDAC HDA4446 series; stainless steel wetted parts and high overload capability withstand hydraulic shock and vibration.
- 100% functional verification under simulated conditions: Every unit is fully tested across pressure and temperature characteristics before shipment, guaranteeing consistency and reliability.
Application Areas
- Pressure monitoring on mobile hydraulic equipment (construction and agricultural machinery)
- Industrial hydraulic power units and pump stations
- Injection molding, die-casting and press systems
- Marine and metallurgical hydraulic circuits
- Test and monitoring systems requiring M12 quick-connect
Expert Maintenance Tips
Install with correct sealing and tighten to the specified 20 Nm torque; avoid over-tightening that could damage threads or the membrane. Ensure the M12 connector is properly mated and sealed to achieve IP67 protection. Maintain clean system media to protect the sensing membrane from particles. Periodically check zero and full-scale stability and recalibrate if necessary. For long-term storage keep dry and avoid extreme temperatures. Always confirm pressure range and output signal compatibility before replacement; never exceed the rated pressure.
