PV7-1X/63-71RE07MC0-16 Rexroth Vane Pump 71 cm³ 160 bar

Model Number	PV7-1X/63-71RE07MC0-16

SKU N/A Categories Hydraulic Pump, Vane Pump

Product Description

Product Overview

The PV7-1X/63-71RE07MC0-16 (Material No. R900506808) is a Bosch Rexroth PV7 Series pilot-operated variable displacement vane pump. With a maximum geometric displacement of 71 cm³/rev, a maximum operating pressure of 160 bar, and a maximum flow rate of 108 L/min (@1450 rpm), this pump is engineered for industrial open-circuit hydraulic applications requiring reliable, precise fluid power.

The PV7 Series is distinguished by its low noise emissions, low pressure pulsation, and precise control behavior — making it an ideal choice for machine tools, hydrostatic bearings, constant pressure systems, and other applications demanding high control accuracy.

As a premium aftermarket alternative to original Bosch Rexroth hydraulic pumps, this product offers 100% direct interchangeability with identical mounting dimensions and performance specifications, requiring zero modification to existing systems.

Every unit undergoes 100% simulated duty cycle testing prior to shipment, guaranteeing performance reliability under actual working conditions.

Technical Specifications

Model: PV7-1X/63-71RE07MC0-16
Material Number: R900506808
Brand: Bosch Rexroth
Series: PV7 Pilot-Operated Variable Vane Pump
Pump Type: Variable Displacement Vane Pump
Max. Geometric Displacement: 71 cm³/rev
Max. Operating Pressure: 160 bar
Max. Flow Rate: 108 L/min (@1450 rpm)
Minimum Speed: 900 rpm
Maximum Speed: 1800 rpm
Direction of Rotation: Clockwise (viewed from shaft end)
Shaft End: Cylindrical Ø32 mm with fitting key, ISO 3019-2
Mounting Flange: 4-hole mounting flange 125B4HW per ISO 3019-2
Seals: NBR (BUNA N)
Hydraulic Fluid: HLP, HLPD, HVLP, HVLPD (mineral oils)
Pressure Port: SAE 1 1/4 in (DN32)
Suction Port: SAE 2 in (DN51)
Max. Drain Port Pressure: 2 bar
Max. Drive Power (@1450 rpm): 33 kW
Max. Torque: 440 Nm
Weight: Approx. 31.98 – 37 kg
Component Series: 1X
Through-Drive Capability: Yes

Key Technical Advantages

1. Low Noise & Low Pulsation Operation
The PV7 Series vane pump achieves exceptionally low noise emissions and pressure pulsation levels through precision engineering and manufacturing. Noise optimization is further enhanced via the adjustable height screw, effectively reducing operational noise. This makes the pump particularly advantageous for noise-sensitive applications such as machine tools and precision machining equipment.

2. Precise Control Characteristics
The pilot-operated control design delivers low hysteresis and high repetition accuracy, enabling precise closed-loop control of pressure and flow. Short control response times, combined with high repetition accuracy and low pressure peaks during down-control, ensure superior system performance.

3. Hydrodynamic Plain Bearings & Extended Service Life
Hydrodynamically lubricated plain bearings significantly extend bearing life. The axial compensation of the displacement element delivers excellent volumetric efficiency. The cast iron housing provides robust protection for internal components, ensuring long-term durability in harsh industrial environments.

4. Flexible Combination & Through-Drive Capability
PV7 Series standard single pumps can be combined into multi-pump assemblies with other Rexroth pumps, including internal gear, external gear, axial piston, and radial piston pumps. Through-drive capability enables flexible configuration for complex multi-pump hydraulic systems.

5. Wide Media Compatibility
Compatible with HLP, HLPD, HVLP, and HVLPD mineral oil-type hydraulic fluids, as well as environmentally friendly HETG and HEES hydraulic oils.

Application Areas

The PV7-1X/63-71RE07MC0-16 variable vane pump is widely deployed across the following applications:

Machine Tool Hydraulics — hydrostatic bearings, feed drives
Constant Pressure Systems — pressure control circuits
Automotive Assembly Lines — robotic arms, conveyor systems, lifting mechanisms
Packaging Machinery — precise flow control
Industrial Automation Equipment
Presses & Clamping Systems

Expert Maintenance Tips

Pre-Start Priming: Prior to initial start-up, fill the pump housing with hydraulic fluid through the drain port to ensure adequate lubrication of internal components.
Fluid Cleanliness: Maintain system fluid cleanliness to ISO 4406 18/16/13 or better to maximize vane and cam ring service life. Install appropriate suction filtration.
Suction Conditions: Maintain suction port absolute pressure between 0.8 bar and 2.5 bar to prevent cavitation. Drain port back pressure must not exceed 2 bar.
Rotation Confirmation: Verify that pump rotation direction matches system requirements before installation. This model is configured for clockwise rotation (viewed from shaft end).
Coupling Alignment: Ensure proper coaxial alignment between pump shaft and drive shaft. Flexible couplings are recommended. Shaft end is cylindrical Ø32 mm with keyway.
Mounting Standards: Mounting and connection dimensions comply with VDMA 24 560/1 and ISO 3019-2 standards, enabling easy integration with standard pump assemblies.
