PVR50-F-F-56-RAA-3180 Yuken Vane Pump 56L/min 210bar

Product Overview

The PVR50-F-F-56-RAA-3180, PVG50-F-T-07-39-LLAA-10, and PVM50-F-F-45-RAA3180 are hydraulic vane pumps from the YUKEN PVR / PVG / PVM series. As a globally recognized hydraulic component manufacturer, YUKEN’s vane pumps are renowned for their stable performance, compact design, low noise, and high efficiency, widely deployed in industrial hydraulic systems and mobile hydraulic equipment.

The PVR series features single vane pumps with a sub-vane structure, delivering high efficiency, low noise, and extended service life. The PVR50-F-F-56-RAA-3180 delivers 56 L/min flow rate, 210 bar maximum pressure, and 3180 RPM maximum speed.

The PVG series features variable displacement vane pumps with pressure-compensated control, automatically adjusting displacement based on system load for energy-efficient operation. The PVG50-F-T-07-39-LLAA-10 delivers 175 bar maximum pressure and 1800 rpm maximum speed.

The PVM series features single vane pumps specifically designed for mobile hydraulic applications, combining stable performance, robust construction, and a wide range of delivery rates. The PVM50-F-F-45-RAA3180 delivers 45 cc/rev displacement and 175 bar maximum pressure.

Designed as 100% interchangeable direct replacements for original YUKEN PVR/PVG/PVM series pumps, these products match OEM specifications in mounting dimensions, porting interfaces, and performance characteristics. Every unit undergoes 100% simulated duty cycle testing prior to shipment, validating volumetric efficiency, mechanical efficiency, and sealing integrity under actual operating load conditions.

Technical Specifications

PVR50-F-F-56-RAA-3180

• Model: PVR50-F-F-56-RAA-3180

• Brand: YUKEN

• Series: PVR Series Single Vane Pump

• Product Type: Fixed Displacement Vane Pump

• Max Working Pressure: 210 bar

• Rated Flow: 56 L/min

• Max Speed: 3180 RPM

• Frequency: 50/60 Hz

• Working Temperature: Ambient temperature and hydraulic fluid temperature

• Material: Cast iron

• Mounting Type: Flange mounting

• Seals: Standard hydraulic seals

• Rotation Direction: Clockwise (“R” designation)

• Self-priming: Yes

• Hydraulic Fluids: Mineral oil and approved hydraulic fluids

PVG50-F-T-07-39-LLAA-10

• Model: PVG50-F-T-07-39-LLAA-10

• Brand: YUKEN

• Series: PVG Series Variable Displacement Vane Pump

• Product Type: Variable Displacement Vane Pump

• Max Working Pressure: 175 bar

• Max Speed: 1800 rpm

• Max Power: 37 kW

• Frequency: 50/60 Hz

• Working Temperature: Up to 80°C

• Material: Cast iron

• Mounting Type: Flange mounting

• Control Type: Manual control

• Self-priming: Yes

• Standard: ISO compliant

PVM50-F-F-45-RAA3180

• Model: PVM50-F-F-45-RAA3180

• Brand: YUKEN

• Series: PVM 50 Series Single Vane Pump

• Product Type: Fixed Displacement Vane Pump

• Geometric Displacement: 35.1 cc/rev (for PVM50-45)

• Max Working Pressure: 175 bar (17.5 MPa)

• Max Flow Rate: 63 L/min

• Max Speed: 2000 rpm

• Min Speed: 600 rpm

• Mass – Flange Mounting: Approx. 12 kg

• Mass – Foot Mounting: Approx. 14.7 kg

• Rotation Direction: Clockwise (“R” designation)

• Mounting Type: Flange connection

• Circuit Type: Open circuit

• Hydraulic Fluids: Mineral oil and approved hydraulic fluids

Key Technical Advantages

1. Sub-Vane Structure for High Efficiency and Low Noise

The PVR/PVM series employs an advanced sub-vane (sub-vane) structure that optimizes contact stress between vanes and the cam ring, significantly reducing friction losses and operating noise. This design ensures high volumetric efficiency and low-noise operation under high-pressure conditions, making it particularly suitable for indoor industrial equipment with strict noise requirements.

2. Pressure-Compensated Control for Energy-Efficient Operation

The PVG series features pressure-compensated control, where pump output flow automatically adjusts based on system load. When the system reaches the set pressure, the pump automatically reduces displacement to only maintain leakage flow, significantly reducing energy loss and heat generation while extending hydraulic system service life.

3. Robust Cast Iron Construction for Extended Service Life

PVR/PVG/PVM series pump housings are precision-cast in ductile iron, offering excellent strength, rigidity, and impact resistance. Critical friction pairs are precision-machined and specially heat-treated, significantly enhancing wear resistance and fatigue strength for long-term reliable operation under continuous high-load conditions.

4. 100% Interchangeability – Zero-Modification Drop-In Replacement

Manufactured to exact OEM mounting dimensions, porting specifications, and performance standards, these pumps achieve 100% interchangeability with original YUKEN PVR/PVG/PVM series units. No machine modifications are required—simply replace and resume operation, minimizing downtime and reducing maintenance costs.

5. 100% Simulated Duty Cycle Testing for Extreme Environment Reliability

Every pump undergoes 100% simulated duty cycle testing before shipment, validating performance under rated pressure and maximum speed conditions—ensuring long-term reliability in demanding industrial hydraulic and mobile equipment applications.

6. Wide Speed Range with Self-Priming Capability

The PVM series supports a wide speed range of 600–2000 rpm, while the PVR50 reaches up to 3180 RPM. All series feature self-priming capability, eliminating the need for additional auxiliary equipment.

7. Modular Configuration for Versatile Application Adaptation

YUKEN vane pump series offer multiple displacement options (PVM50 series covers 9.5–40.5 cc/rev), multiple mounting styles (flange mounting/foot mounting), and various port configurations. This modular design enables rapid adaptation to injection molding machines, presses, machine tools, forklifts, agricultural machinery, and other diverse applications.

Application Areas

• Injection Molding Machinery: Hydraulic system supply

• Presses & Stamping Equipment: Hydraulic press and stamping systems

• Machine Tools: CNC machines, machining center hydraulic systems

• Material Handling: Forklift hydraulic systems, lift platforms

• Agricultural Machinery: Combine harvesters, tractor hydraulic systems

• Construction Equipment: Mini excavators, loader hydraulic systems

• Industrial Hydraulic Systems: General industrial hydraulic power units

• Metallurgical Equipment: Metallurgical machinery hydraulic transmission systems

Expert Maintenance Tips

1. Pre-Installation Preparation: Before using the YUKEN vane pump, read and understand the complete instruction manual. For first commissioning, fill the pump housing with hydraulic fluid through the case drain port—never operate the pump without fluid.

2. Suction Line Design: The inlet line should be short and large in diameter, with inlet filter rating not less than 100 µm and flow capacity ≥ 2× pump rated flow. Strictly prevent air suction and cavitation, ensuring suction port pressure is not lower than -0.16 bar (relative pressure).

3. Suction Port Pressure Requirements: PVR/PVG/PVM series vane pumps have specific suction port pressure requirements. Ensure the suction line is unobstructed to prevent cavitation damage. Recommended suction port vacuum should not exceed 0.16 bar (0.84 bar absolute pressure).

4. Coupling Alignment: Precise alignment between the pump shaft and drive shaft is required with minimal tolerance. After installation, manually rotate the coupling to verify smooth operation. The pump shaft must not bear radial or axial external loads.

5. Oil Cleanliness Control: YUKEN vane pumps require high fluid cleanliness. Recommended system filtration not less than ISO 4406 19/17/14. Regular oil analysis is recommended with filter change intervals adjusted based on contamination levels.

6. Operating Temperature Control: Ensure the hydraulic system operating oil temperature remains within the recommended range (30–60°C) to prevent viscosity reduction and seal degradation from excessive temperatures. PVG series maximum operating temperature is 80°C.

7. Pressure Adjustment (PVG Series): The PVG series is a variable displacement vane pump. During commissioning, set the pressure compensator valve according to the instruction manual specifications. Avoid prolonged operation above the rated pressure.

8. Regular Inspection Schedule: Regular inspection of the hydraulic system and pump is recommended. Check hydraulic fluid level daily and monitor operating temperature, noise levels, and case drain flow regularly. Abnormal increases may indicate internal wear or seal degradation.
