SVPF-12 YUKEN Variable Vane Pump 12 L/min 70 bar

Product Overview

The SVPF Series, manufactured by YUKEN, is a family of quiet, compact variable displacement vane pumps specifically developed for low-pressure applications. Available in multiple sizes including SVPF-12, SVPF-20, SVPF-30, and SVPF-40, the series covers a displacement range of 12–40 ml/r with adjustable working pressure from 20 to 70 bar to meet diverse system requirements.

The SVPF Series pumps feature low noise, compact dimensions, high efficiency, long service life, and rapid response. With adjustable pressure and flow rate, these pumps are ideal for small and light equipment where installation space and noise levels are critical constraints, such as toll collection machines and shoe-making machinery.

Our products are manufactured to be 100% interchangeable with YUKEN original specifications—a true “drop-in” replacement solution. Every unit undergoes 100% full-load and flow-matching testing under simulated operating conditions before shipment, ensuring volumetric efficiency, flow rate, and noise performance meet or exceed original specifications at rated pressure.

Technical Specifications

SVPF-12

• Product Type: Variable Displacement Vane Pump

• Brand Compatibility: YUKEN

• Series: SVPF

• Displacement: 6.7 cm³/r

• Flow Rate (@1800 rpm): 12 L/min

• Flow Rate (@1500 rpm): 10 L/min

• Rated Pressure (Selectable): 20 bar / 35 bar / 55 bar / 70 bar

• Maximum Speed: 1800 r/min

• Minimum Speed: 800 r/min

• Design Number: 20

• Shaft Diameter (Standard): φ12.7 mm

• Shaft Diameter (Type B): φ15.875 mm

• Fluid Compatibility: Petroleum-based hydraulic oil (ISO VG32 or VG46)

SVPF-20

• Product Type: Variable Displacement Vane Pump

• Brand Compatibility: YUKEN

• Series: SVPF

• Flow Rate (@1800 rpm): 20 L/min

• Rated Pressure (Selectable): 20 bar / 35 bar / 55 bar / 70 bar

• Maximum Speed: 1800 r/min

• Minimum Speed: 800 r/min

• Design Number: 20

• Shaft Diameter (Standard): φ12.7 mm / φ15.875 mm (Type B)

• Fluid Compatibility: Petroleum-based hydraulic oil (ISO VG32 or VG46)

SVPF-30

• Product Type: Variable Displacement Vane Pump

• Brand Compatibility: YUKEN

• Series: SVPF

• Flow Rate (@1800 rpm): 30 L/min

• Rated Pressure (Selectable): 20 bar / 35 bar / 55 bar / 70 bar

• Maximum Speed: 1800 r/min

• Minimum Speed: 800 r/min

• Design Number: 20

• Shaft Diameter: φ19.05 mm

• Fluid Compatibility: Petroleum-based hydraulic oil (ISO VG32 or VG46)

SVPF-40

• Product Type: Variable Displacement Vane Pump

• Brand Compatibility: YUKEN

• Series: SVPF

• Displacement: 40 cm³/r

• Flow Rate (@1800 rpm): 40 L/min

• Rated Pressure: 70 bar

• Peak Pressure: Up to 210 bar (variant-dependent)

• Speed Range: 600–1800 r/min

• Design Number: 20

• Shaft Diameter: φ19.05 mm

• Mounting: Flange-mounted

• Rotation: Clockwise (viewed from shaft end)

• Fluid Compatibility: Petroleum-based hydraulic oil (ISO VG32 or VG46)

SVPF-15-70-20

• Product Type: Variable Displacement Vane Pump

• Brand Compatibility: YUKEN

• Series: SVPF-15

• Flow Rating: 15 L/min

• Rated Pressure: 70 bar

• Design Number: 20

• Speed Range: 600–1800 r/min

• Fluid Compatibility: Petroleum-based hydraulic oil (ISO VG32 or VG46)

SVPF-12-55-20

• Product Type: Variable Displacement Vane Pump

• Brand Compatibility: YUKEN

• Series: SVPF-12

• Displacement: Approx. 6.7 cm³/r

• Flow Rating: 12 L/min

• Rated Pressure: 55 bar

• Design Number: 20

• Speed Range: 600–1800 r/min

• Fluid Compatibility: Petroleum-based hydraulic oil (ISO VG32 or VG46)

Key Technical Advantages

1. Adjustable Pressure and Flow for Maximum System Flexibility
The SVPF Series pumps support independent adjustment of both working pressure and output flow rate. By adjusting the pressure compensator valve and flow control valve on the pump body, users can flexibly set the working pressure within the 20–70 bar range according to actual system requirements, achieving optimal system matching and energy consumption optimization.

2. Industry-Leading Low-Noise Performance
The SVPF Series features optimized fluid flow path design and structural vibration damping measures, resulting in exceptionally low operating noise. The optimized vane-to-stator contact curve effectively reduces pressure pulsation and fluid-borne noise, making it particularly suitable for indoor light equipment environments with strict noise limitations, such as toll collection machines and shoe-making machinery.

3. Compact Dimensions, Space-Saving Design
The SVPF Series employs a highly integrated compact design that significantly reduces pump body size while maintaining performance. This feature makes it an ideal hydraulic power choice for small equipment and light machinery where installation space is constrained.

4. High Efficiency and Extended Service Life
Precision-ground vane and stator mating surfaces minimize internal leakage and improve volumetric efficiency. Critical components are manufactured from wear-resistant materials, ensuring stability and reliability over long-term operation. The pump responds rapidly, quickly tracking system load changes.

5. 100% Drop-In Interchangeability – Zero Retrofit Cost
Manufactured to exact YUKEN original specifications—mounting dimensions, port locations, and shaft configurations are identical to the original. No piping modifications or installation adapters are required for direct replacement.

6. 100% Full-Load Tested for Proven Reliability
Every pump undergoes rigorous full-pressure and flow-matching testing before shipment. Critical components are manufactured from premium materials with advanced heat treatment processes, ensuring stability and reliability under rated operating conditions.

Application Areas

• Toll Collection Machines: Providing stable, low-noise hydraulic power

• Shoe Manufacturing Machinery: Ideal hydraulic power source for small, lightweight equipment

• Small Packaging Equipment: Reliable hydraulic power in compact installation spaces

• Agricultural Seeding Machinery: SVPF-12/20/30 suited for small walk-behind (≤2 rows), medium towed (4-6 rows), and large self-propelled (8-12 rows) seeders respectively

• Small Presses & Stamping Equipment: Precise flow control for low-pressure variable applications

• Automation Auxiliary Equipment: Hydraulic drive for clamping, positioning, and other auxiliary functions

• Low-Pressure Power Units: Core power source for indoor, quiet-operation hydraulic stations

Expert Maintenance Tips

1. Installation Precautions

• Before installation, verify that the pump’s rotation direction matches system requirements—SVPF Series standard configuration is clockwise rotation (viewed from the shaft end).

• Suction piping should be as short as possible, minimizing unnecessary restrictions such as elbows, to ensure the pump does not exceed its allowable suction vacuum rating.

• The pump housing must not bear piping loads; suction and discharge lines must have independent supports.

• Confirm shaft configuration matches the coupling—standard shaft diameter φ12.7 mm, Type B shaft diameter φ15.875 mm, 30/40 size shaft diameter φ19.05 mm.

2. Pre-Startup Checklist

• Before startup, verify oil level in the reservoir is adequate and fluid type is correct (ISO VG32 or VG46 anti-wear hydraulic oil recommended).

• Confirm all piping connections are secure with no leakage.

• Prime the pump by filling the housing with oil before first startup to prevent dry running.

3. Pressure and Flow Adjustment

• The SVPF Series supports on-site pressure and flow adjustment. Adjustments should be made slowly while the system is running to avoid sudden large changes that could cause system shock.

• Pressure settings should be based on actual system requirements; prolonged operation above rated pressure is not recommended.

4. Fluid Management

• ISO VG32 or VG46 anti-wear hydraulic oil is recommended.

• Fluid cleanliness should be maintained at NAS 9 or higher—contamination is the leading cause of premature vane pump failure.

• Regularly check oil temperature to ensure it does not exceed 60°C.

5. Scheduled Maintenance

• Replace hydraulic oil and filters every 2000 operating hours or annually.

• If flow degradation or pressure fluctuation occurs, first check for clogged suction filters or degraded fluid before considering cartridge wear.

• The SVPF Series features a cartridge-type construction—pump cartridges can be replaced independently without removing the entire pump from the system, significantly reducing downtime.
