T67CBASB25B14B223R03B100 Parker Denison Vane Pump 320bar
| Model Number | T67BBG Y12 Y09 10 4L00 A111, T67CBASB25B14B223R03B100 |
|---|
Product Description
Product Overview
The T67CBASB25B14B223R03B100 is a high-pressure triple fixed-displacement vane pump from the Parker Denison T67CBAS series (Order Code: 054-51883-003). Engineered with a dowel pin double-lip vane mechanism, this pump is purpose-built for industrial high/low hydraulic circuits where three independent pumping sections deliver optimized flow at varying pressure levels — enabling intelligent circuit design with minimal energy waste.
Manufactured to exact Parker Denison dimensional and performance specifications, this pump guarantees 100% drop-in interchangeability with the original Parker Denison unit. Every pump undergoes comprehensive simulated duty-cycle testing prior to shipment — validating displacement accuracy, pressure ripple (±2 bar), volumetric efficiency, and noise levels — ensuring performance that fully matches OEM standards.
Technical Specifications
- Model: T67CBASB25B14B223R03B100 (Order No. 054-51883-003)
- Series: Parker Denison T67CBAS Triple Vane Pump
- Cartridge Configuration: P1 (Shaft End) = B25 / P2 (Mid) = B14 / P3 (Cover End) = B22
- P1 Displacement: 79.3 ml/rev
- P2 Displacement: 44.2 ml/rev
- P3 Displacement: 70.3 ml/rev
- Total Displacement: 193.8 ml/rev
- P1 Rated Pressure: 280 bar (Peak: 320 bar)
- P2 Rated Pressure: 300 bar (Peak: 320 bar)
- P3 Rated Pressure: 300 bar (Peak: 320 bar)
- Maximum Speed: 3000 rpm
- Minimum Stable Speed: 600 rpm
- Volumetric Efficiency: ≥94% (typical)
- Pressure Ripple: ±2 bar (low-ripple design)
- Rotation: Clockwise viewed from shaft end (R = Right)
- Shaft Type: 3 = SAE BB Splined Shaft
- Port Orientation: 03 = S-type (common inlet, independent P1/P2/P3 outlets)
- Seal Class: 1 = S1 NBR (Nitrile Rubber) for mineral-based hydraulic oil
- Design Code: B
- Port Connection: 00 = Standard metric/SAE threaded ports
- Housing Material: High-strength cast iron
- Vane Type: Dowel Pin Double-Lip Vane
- Weight: Approx. 43.0 kg
- Mounting Flange: SAE C 6-bolt J744c standard
Key Technical Advantages
Dowel Pin Double-Lip Vane Technology
The pump features Parker Denison’s patented dowel pin-guided double-lip vane architecture. Vanes are positively locked to the rotor via precision dowel pins, eliminating the fatigue failure mode inherent in spring-loaded vane designs under high-pressure operation. The double-lip geometry creates a pressure-balanced sealing interface, dramatically reducing contact stress between vane tips and the cam ring. This design substantially enhances contamination resistance — tolerating particle levels up to ISO 4406 18/16/13 — and extends service life by more than 2× compared to conventional vane structures.
The pump features Parker Denison’s patented dowel pin-guided double-lip vane architecture. Vanes are positively locked to the rotor via precision dowel pins, eliminating the fatigue failure mode inherent in spring-loaded vane designs under high-pressure operation. The double-lip geometry creates a pressure-balanced sealing interface, dramatically reducing contact stress between vane tips and the cam ring. This design substantially enhances contamination resistance — tolerating particle levels up to ISO 4406 18/16/13 — and extends service life by more than 2× compared to conventional vane structures.
High Volumetric Efficiency & Wide Speed Envelope
Precision-ground cam ring profiles and tightly controlled side plate clearances deliver a typical volumetric efficiency of 94%, minimizing internal leakage, energy loss, and heat generation. The wide operational speed range (600–3000 rpm) enables stable low-speed operation during cold-start conditions without stalling risk, while supporting full-pressure operation down to 600 rpm — making it ideal for servo-driven variable-speed energy-saving systems.
Precision-ground cam ring profiles and tightly controlled side plate clearances deliver a typical volumetric efficiency of 94%, minimizing internal leakage, energy loss, and heat generation. The wide operational speed range (600–3000 rpm) enables stable low-speed operation during cold-start conditions without stalling risk, while supporting full-pressure operation down to 600 rpm — making it ideal for servo-driven variable-speed energy-saving systems.
Low Noise & Low Pressure Ripple Design
A non-contact side plate configuration combined with optimized relief groove geometry constrains pressure ripple to ±2 bar, effectively reducing piping vibration and fluid-borne noise. Operating noise is 3–5 dB(A) lower than conventional vane pumps, making it particularly suitable for noise-sensitive indoor industrial environments and railway applications.
A non-contact side plate configuration combined with optimized relief groove geometry constrains pressure ripple to ±2 bar, effectively reducing piping vibration and fluid-borne noise. Operating noise is 3–5 dB(A) lower than conventional vane pumps, making it particularly suitable for noise-sensitive indoor industrial environments and railway applications.
Cartridge-Based Modular Maintenance
The triple pump employs independent plug-in cartridge sections, each removable without disconnecting the main pump body from system piping. On-site maintenance requires only cartridge-level replacement for wear components or displacement changes, reducing downtime to 30–60 minutes. A single pump body accommodates multiple cartridge displacement options, streamlining spare parts inventory and installation design.
The triple pump employs independent plug-in cartridge sections, each removable without disconnecting the main pump body from system piping. On-site maintenance requires only cartridge-level replacement for wear components or displacement changes, reducing downtime to 30–60 minutes. A single pump body accommodates multiple cartridge displacement options, streamlining spare parts inventory and installation design.
Multi-Orientation Mounting & Flexible Port Configuration
The pump supports horizontal, vertical, and angular mounting orientations with customizable port direction. Triple pump configurations offer up to 128 installation combinations, accommodating complex hydraulic system integration in space-constrained environments.
The pump supports horizontal, vertical, and angular mounting orientations with customizable port direction. Triple pump configurations offer up to 128 installation combinations, accommodating complex hydraulic system integration in space-constrained environments.
Application Areas
- Industrial Presses: High/low composite circuits for pressing and rapid return — P1 delivers high-pressure low-flow for tonnage, P2/P3 supply high flow for rapid approach
- Injection Molding Machines: Multi-stage pressure/flow requirements for clamping, injection, and holding — triple independent supply enables precise energy management
- Die Casting Machines: High clamping force with fast cycle rates — high volumetric efficiency minimizes oil temperature rise
- Machine Tools: Independent supply for feed drives and clamping circuits — low ripple ensures machining precision
- Metallurgical Equipment: Mill screw-down systems, continuous casting vibration tables — heavy-duty continuous operation
- Railway Equipment: Hydraulic suspension and braking systems — meets stringent noise and reliability requirements
- Marine Hydraulics: Deck machinery, steering gear systems — compatible with mineral and fire-resistant fluids
Expert Maintenance Tips
- Shaft Alignment: Pump-to-driver concentricity must be maintained within φ0.1 mm. A flexible coupling is strongly recommended to absorb misalignment and prevent bearing damage from bending moments or radial loads.
- Suction Line Requirements: Inlet vacuum must not exceed 110 mm water column. Mount the pump as close to the reservoir as possible with suction lift not exceeding 500 mm. All suction line connections and flanges must be airtight — air ingress causes cavitation, increased noise, and reservoir foaming.
- Fluid Cleanliness: Maintain hydraulic oil cleanliness at ISO 4406 18/16/13 or better. Install a 10 μm absolute filter on the return line. While the double-lip vane design offers superior contamination tolerance, prolonged operation above specified cleanliness levels will accelerate cam ring and vane wear.
- Temperature & Viscosity Management: Keep continuous oil temperature below 60°C. Start-up viscosity should be within 25–75 cSt. For cold starts, run the pump at 600 rpm no-load for 5–10 minutes to warm the fluid before gradually applying load above 20°C oil temperature.
- Seal Material Compatibility: This pump is equipped with Seal Class “1” (NBR nitrile rubber), suitable only for mineral-based hydraulic oils. If the system operates with phosphate ester fire-resistant fluids or synthetic lubricants, the seal kit must be upgraded to Seal Class “5” (FKM fluorocarbon rubber) to prevent seal swelling and failure.
- Preventive Maintenance Schedule: Inspect vane wear and cartridge side plate clearances every 5,000 operating hours. Replace cartridge assemblies every 10,000 hours or when fluid cleanliness degrades. The cartridge design enables field replacement in 30–60 minutes without removing the pump from the system.
